Xerox WorkCentre 5230 User Manual

February, 2008
2-540
WorkCentre 5225, 5230
074-211, 071-940
Launch Version
Status Indicator Raps
074-211 Tray 4 Broken RAP
BSD-ON:7.4/7.6
The Tray 4 Paper Size Switch failed.
Initial Actions
• Reload the tray correctly.
• Check the operation of the tray actuator.
• Power OFF/ON
Procedure
[For 2TM]
Remove Trays 3 and 4. Replace Tray 3 with Tray 4. [074-211] occurs.
YN
Replace the faulty part of the Tray 4 Actuator.
Check the installation of the Tray 4 Paper Size Switch. The Tray 4 Paper Size Switch is
installed correctly.
YN
Install the Tray 4 Paper Size Switch correctly.
Go to the OF 2 (SIZE SWITCH ASSY RAP).
[For TTM]
Check the Tray 4 Actuator. The Tray 4 Actuator is not distorted.
YN
Replace the faulty part of the Tray 4 Actuator.
Check the installation of the Tray 4 Paper Size Switch. The Tray 4 Paper Size Switch is
installed correctly.
YN
Install the Tray 4 Paper Size Switch correctly.
Go to the OF 2 (SIZE SWITCH ASSY RAP).
071-940 Tray 4 Lift Up RAP
BSD-ON:7.1
The Tray 4 Level Sensor does not turn on within the designated time.
Initial Actions
• Remove and reinsert Tray 4
• Realign paper in the tray
• Object other than paper is in the tray
Procedure
1. Tray Level Sensor
2. Drive system from motor to bottom plate

Xerox WorkCentre 5230 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Standard input capacity	500 sheets
Internal memory	No MB
Type	Digital copier
