February, 2008
2-514
WorkCentre 5225, 5230
062-357, 062-360
Launch Version
Status Indicator Raps
062-357 CCD Fan Failure RAP
CCD Fan Failure
Initial Actions
• Check the vent has no foreign object and is not clogged.
• Check there is no dust on the Fan Blade.
Procedure
Remove the Platen Glass. Execute Component Control [062-017 CCD Fan]. The CCD Fan
operates.
YN
Replace the CCD Fan (PL 6.4).
Check CCD Fan connections and wiring for damage.
062-360 Carriage Position RAP
BSD-ON: 6.3
• An error occurred while counting the pulses of the Carriage Motor.
• After the Carriage Motor turned On, the IIT Registration Sensor did not turn On within the spec-
ified time.
Procedure
Check the Carriage Rail for dirt or contamination or distortion. Dirt or contamination or distor-
tion is found in the Carriage Rail.
YN
Clean the rails or correct the distortion (PL 11.4).
Execute Component Control [062-212 IIT Registration Sensor]. Actuate the IIT Registration
Sensor with paper. The display changes.
YN
Check the connections of P/J728 and P/J7193. P/J728 and P/J7193 are connected
correctly.
YN
Connect P/J728 and P/J7193.
Check the wire between J728 and J7193 for an open circuit or a short circuit (BSD 6.3
Flag 2/Flag 3).
The wire between J728 and J7193 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the IIT/IPS PWB P7193-B10 (+) and GND (-) (BSD 6.3 Flag
2/Flag 3).
The voltage is approx. +5VDC.
YN
Replace the IIT/IPS PWB (PL 11.3).
Measure the voltage between the IIT/IPS PWB P7193-B12 (+) and GND (-) (BSD 6.3 Flag
2).
Actuate the IIT Registration Sensor (PL 11.4) with paper. The voltage changes.
YN
Replace the IIT Registration Sensor (PL 11.4).
Replace the IIT/IPS PWB (PL 11.3).
Alternately execute Component Control[062-005 Carriage Motor SCAN ON] and Component
Control[062-006 Carriage Motor RETURN ON].
The Carriage Motor starts up.
YN
Check the connection P/J721. P/J721 is connected correctly.
YN
Connect P/J721.
Check the wires on J721 for an open circuit or a short circuit (BSD 6.3 Flag 1). The
wires on J721 are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
A B
To Next Page
