February, 2008
2-93
WorkCentre 5225, 5230
010-318
Status Indicator Raps
Launch Version
010-318 Hot-Sagging Recovery Failure RAP
BSD-ON:4.1/10.1
The Rear Thermistor detected that the machine does not recover from Hot-Sagging in time.
Initial Actions
• Power OFF/ON
Procedure
Check for paper on the Fuser. The Fuser has no paper wrapped round it.
YN
Remove the paper.
Check the installation of the Fuser Unit. The Fuser Unit is securely installed.
YN
Install the Fuser Unit securely.
Close the LH Cover and the Front Cover.
Execute Component Control[071-036 Main Motor ON]. The Main Motor can be heard.
YN
Go to the OF 3 (MAIN DRIVE ASSY RAP).
Check the resistance of the Rear Thermistor between J600-2 and J600-4 (BSD 10.1 Flag 2/
Flag 3).
The resistance is 3k ohms or higher.
YN
Replace the Fuser Unit (PL 5.1).
Check the wire between P/J410 and J600 for an open circuit or a short circuit (BSD 10.1 Flag
2/Flag 3).
The wire between J410 and J600 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Replace the Fuser Unit (PL 5.1). If the problem persists, replace the Power Unit (PL 9.1). If the
problem persists, replace the MCU PWB (PL 9.1).
To Next Page
