February, 2008
2-527
WorkCentre 5225, 5230
072-210
Status Indicator Raps
Launch Version
072-210 Tray 2 Lift Up Failure RAP
BSD-ON:7.8
After the Tray 2 Feed/Lift Motor turned On, the Tray 2 Level Sensor did not turn On within the
specified time.
Initial Actions
Reload paper in the tray correctly.
Remove foreign substances in the tray.
Power OFF/ON
Procedure
Remove the tray and reinstall. The Tray 2 Feed/Lift Motor can be heard.
YN
Execute Component Control[071-008 Tray 2 Feed/Lift Motor ON]. The Tray 2 Feed/Lift
Motor (PL 2.3) can be heard.
YN
Check the connections of P/J202, P/J602 and P/J409. P/J202, P/J602 and P/
J409 are connected correctly.
YN
Connect P/J202, P/J602 and P/J409.
Remove the Tray 1 Feed/Lift Motor (PL 2.3) and the Tray 2 Feed/Lift Motor (PL 2.3).
Replace the Tray 2 Feed/Lift Motor with the Tray 1 Feed/Lift Motor.
Execute Component Control[071-008 Tray 2 Feed/Lift Motor ON]. The Tray 1 Feed/
Lift Motor (PL 2.3) can be heard.
YN
Return the Tray 1 Feed/Lift Motor to its original position.
Check the wire between J202 and J409 for an open circuit or a short circuit
(BSD 7.8 Flag 1).
The wire between J202 and J409 is conducting without
an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the MCU PWB (PL 9.1).
Return the Tray 1 Feed/Lift Motor to its original position.
Replace the Tray 2 Feed/Lift Motor (PL 2.3).
Go to the OF 2 (SIZE SWITCH ASSY RAP).
Check the installation of the Tray 2 Level Sensor (PL 2.3) and the operation of the actuator.
The Tray 4 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 4 Level Sensor.
Execute Component Control[071-207 Tray 2 Level Sensor]. Manually activate the Tray 2 Level
Sensor (PL 2.3).
The display changes.
YN
Check the connections of P/J102, P/J602 and P/J409. P/J102, P/J602 and P/J409
are connected correctly.
YN
Connect P/J102, P/J602 and P/J409.
Check the wire between J102 and J409 for an open circuit or a short circuit (BSD 7.8 Flag
2/Flag 3).
The wire between J102 and J409 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P409B-7 (+) and GND (-) (BSD 7.8 Flag 3).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P409B-9 (+) and GND (-) (BSD 7.8 Flag 2).
Activate the actuator of the Tray 2 Level Sensor (PL 2.3). The voltage changes.
YN
Replace the Tray 2 Level Sensor (PL 2.3).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
