Xerox WorkCentre 5230

February, 2008
2-686
WorkCentre 5225, 5230
124-374, 124-380
Launch Version
Status Indicator Raps
124-374 IOT IM Device Driver Software RAP
BSD-ON:16.1
Due to an error in the software of the IOT IM Device Driver, subsequent processes cannot be per-
formed.
Procedure
Reload Software (ADJ 9.3.1).
If the problem persists reinstall or replace the DDR DIMM (PL 9.2).
If the problem persists replace the ESS PWB (PL 9.2).
124-380 CRUM Market (2)
There is a general CRUM control failure.
Procedure
Check the electrical connections on the ESS PWB and MCU PWB. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 9.2)
If the problem persists replace the MCU PWB (PL 9.1).
