Xerox WorkCentre 5230

February, 2008
2-565
WorkCentre 5225, 5230
081-799
Status Indicator Raps
Launch Version
081-799 Registered Destination RAP
The Fax Send destination telephone number is not registered in the Address Book.
Initial Actions
Check the entries in the Address Book.
Check the Send destination telephone number and repeat the operation.
Procedure
Pull out and insert the FAX PWB (PL 9.3) Switch on the power. The problem persists The
problem persists.
YN
Return to Service Call Procedures.
Check the connection of each FAX PWB (PL 9.3) connector. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the FAX PWB (PL 9.3).
