WorkCentre 5225, 5230

012-243

Launch Version

Status Indicator Raps

012-243 Booklet Folder Home Sensor ON Fail

BSD-ON:12.17

Folder Home Sensor is not turned on after the lapse of 500ms from Motor ON while Booklet

Knife is returning to Home.

Initial Actions

• The Folder Home Sensor for improper installation

• The Folder Home Sensor connectors for connection failure

• The Booklet Fold Knife Motor connectors for connection failure

• The Knife drive mechanism for a foreign substance

Procedure

Manually move the Booklet Tamper to both ends. Enter Component Control [013-022, Folder

Knife Motor FWD] and [013-023, Folder Knife Motor REV] alternately. Select Start.

The

Booklet Folder Roll Motor energizes.

Select Stop. Check continuity between the Booklet Folder Knife Motor and the Booklet

PWB and between the Booklet PWB and the Finisher PWB.

The continuity check is

OK.

Repair the open circuit or short circuit.

Replace the Booklet Folder Knife Motor (PL 23.15). If the problem continues, replace the

Booklet PWB (PL 23.21). If the problem persists, replace Finisher PWB (PL 23.16).

Select Stop. Select [13-101, Folder Home Sensor]. Select Start. Block/unblock the Folder

Home Sensor. The display changed.

Select Stop. Check continuity between the Folder Home Sensor and the Booklet PWB

and between the Booklet PWB and the Finisher PWB.

The continuity check is OK.

Repair the open circuit or short circuit.

Replace the Folder Home Sensor (PL 23.15). If the problem continues, replace the Book-

let PWB (PL 23.21). If the problem persists, replace Finisher PWB (PL 23.16).

Select Stop. If the problem continues, replace the Finisher PWB (PL 23.16).
