February, 2008
2-709
WorkCentre 5225, 5230
133-280, 133-281
Status Indicator Raps
Launch Version
133-280 Fax Option Slot 1 Board RAP
BSD-ON:17.1
Failure was detected on the Fax Option Slot 1 board.
Procedure
Pull out and insert the FAX PWB (PL 9.3) Switch on the power. The problem persists.
YN
Service Call Procedures.
Check the connection of each FAX PWB (PL 9.3) connector. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Service Call Procedures.
Replace the FAX PWB (PL 9.3).
133-281 Received unknown message RAP
BSD-ON:17.1
A message not specified in I/F settings was received from the Fax Card.
Procedure
Pull out and insert the FAX PWB (PL 9.3) Switch on the power. The problem persists.
YN
Service Call Procedures.
Check the connection of each FAX PWB (PL 9.3) connector. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Service Call Procedures.
Replace the FAX PWB (PL 9.3).
