WorkCentre 5225, 5230
IQ7, IQ8
Launch Version
Image Quality
IQ7 Deletion RAP
Part of the image is missing.
Procedure
Check the paper type. Paper used is within specifications.
YN
Use paper within specifications.
Use paper from a freshly opened packet. The problem reoccurs.
YN
End
Remove the Xero/Developer Cartridge and reinstall. Turn the power Off/On and print. The
problem reoccurs.
YN
End
Install a new Xero/Developer Cartridge (PL 4.1). Turn the power Off/On and print. The prob-
lem reoccurs.
YN
End
Check the surface of the BTR for distortion. There is no distortion on the surface of the
BTR.
YN
Replace the BTR (PL 2.6).
Replace the MCU PWB (PL 9.1). If the problem persists, replace the ESS PWB (PL 9.2).
IQ8 Skew/Misregistration RAP
Printed images are not parallel to the edges of the paper.
Procedure
Check the location where the machine is installed. The machine is installed on a stable hor-
izontal surface.
YN
Install the machine on a stable horizontal surface.
Remove the Xero/Developer Cartridge (PL 4.1) and reinstall. Turn the power Off/On and print.
The problem reoccurs.
YN
End
Check the installation of the Paper Cassette. The Paper Cassette is correctly installed.
YN
Install the Paper Cassette correctly.
Check for distortion in the paper delivery path. There is no distortion in the paper delivery
path.
YN
Correct the distortion or replace the distorted part.
Replace the MCU PWB (PL 9.1). If the problem persists, replace the ESS PWB (PL 9.2).
To Next Page
