February, 2008
2-356
WorkCentre 5225, 5230
024-959, 024-960
Launch Version
Status Indicator Raps
024-959 Tray 1 size mismatch RAP
Paper is loaded in Tray 1 but the tray is unable to detect the paper size.
Initial Actions
• Refer to BSD 7.1.
• Check the operation of the guide.
Procedure
Remove Trays 1 and 2. Replace Tray 1 with Tray 2. [024-959] occurs.
YN
Replace the faulty part of the Tray 1 Actuator.
Check the installation of the Tray 1 Paper Size Switch. The Tray 1 Paper Size Switch is
installed correctly.
YN
Install the Tray 1 Paper Size Switch correctly.
Go to the BSD 7.1 Tray 1 Paper Size Sensing and check the connectors.
024-960 Tray 2 size mismatch RAP
Paper is loaded in Tray 2 but the tray is unable to detect the paper size.
Initial Actions
• Refer to BSD 7.2.
• Check the operation of the guide.
Procedure
Remove Trays 1 and 2. Replace Tray 2 with Tray 1. [024-960] occurs.
YN
Replace the faulty part of the Tray 2 Actuator.
Check the installation of the Tray 2 Paper Size Switch. The Tray 2 Paper Size Switch is
installed correctly.
YN
Install the Tray 2 Paper Size Switch correctly.
Go to the BSD 7.2 Tray 2 Paper Size Sensing and check the connectors.
To Next Page
