WorkCentre 5225, 5230
116-790, 116-790
Launch Version
Status Indicator Raps
116-790 Stapling Canceled RAP (A-Finisher)
BSD-ON:12.5
When Staple was specified, there were no staples.
Initial Actions
Power Off/On
Procedure
Execute Component Control [012-242 Low Staple Sensor]. Install and remove the Staple Pin
Cartridge.
The display changes.
YN
Check the Staple Pin Cartridge for failure or foreign substances. There are no foreign sub-
stances and nothing has failed.
YN
Repair the failure and remove the foreign substances.
Check the connections of P/J8731 and P/J8701. P/J8731 and P/J8701 are con-
nected correctly.
YN
Connect P/J8731 and P/J8701.
Check the wire between J8731 and J8701 for an open circuit or a short circuit (BSD
12.5).
The wire between J8731 and J8701 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P/J8701-5 (+) and GND (-) (BSD 12.5).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 22.7).
Measure the voltage between the Finisher PWB P/J8701-7 (+) and GND (-) (BSD 12.5).
Install and remove the Staple Pin Cartridge.
The voltage changes.
YN
Replace the Finisher PWB (PL 22.7).
Replace the Staple Assembly (PL 22.4) If the problem persists, replace the Finisher PWB
(PL 22.7).
Replace the Finisher PWB (PL 22.7) If the problem persists, replace the MCU PWB (PL 9.1).
116-790 Stapling Canceled RAP (SB-Finisher)
BSD-ON:12.21
When Staple was specified, there were no staples.
Initial Actions
Power Off/On
Procedure
Execute Component Control [012-242 Low Staple Sensor]. Install and remove the Staple Pin
Cartridge.
The display changes.
YN
Check the Staple Pin Cartridge for failure or foreign substances. There are no foreign sub-
stances and nothing has failed.
YN
Repair the failure and remove the foreign substances.
Check the connections of J8886 and P/J8981. J8886 and P/J8981 are connected
correctly.
YN
Connect J8886 and P/J8981.
Check the wire between J8886 and J8981 for an open circuit or a short circuit (BSD 12.21).
The wire between J8886 and J8981 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB J8886-5 (+) and GND (-) (BSD 12.21).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 22.7).
Measure the voltage between the Finisher PWB J8886-7 (+) and GND (-) (BSD 12.21).
Install and remove the Staple Pin Cartridge.
The voltage changes.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Staple Assembly (PL 22.4) If the problem persists, replace the Finisher PWB
(PL 23.16).
Replace the Finisher PWB (PL 23.16) If the problem persists, replace the MCU PWB (PL 9.1).
