WorkCentre 5225, 5230
Launch Version
General Procedures
711-142 DADF Tail Edge Fine Adjustment (Side1) Replace
All
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Rewrites all
data of 711-029 to 711-037 with specified data.
711-143 DADF Tail Edge Fine Adjustment (Side2) Replace
All
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Rewrites all
data of 711-043 to 711-051 with specified data.
711-144 Vertical Ratio Fine Adjustment Replace All 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor. Rewrites all data of 711-057 to 711-065 with specified data.
711-145 T/A Roll Transport Speed Adjustment (Side1)
Replace All
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor. Rewrites all data of 711-070 to 711-078 with specified
data.
711-146 T/A Roll Transport Speed Adjustment (Side2)
Replace All
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor. Rewrites all data of 711-080 to 711-088 with specified
data.
711-150 Loop Amount Adjustment (Side1) (x1 Pulse) 3 0~9 0.6835mm Initial value 3.6mm (172 pulse, 130 pulse for High Speed mode) +4.1mm/-2.1mm 10
pulse increments
711-151 Loop Amount Adjustment (Side2) (x6 Pulse) 5 0~14 0.4581mm Initial value 4.0mm (256 pulse) +4.1mm (346 pulse) / -2.3mm (206 pulse) 10 pulse
increments
711-152 Simplex Speed Mode Switch 0 0~1 - 0: High Speed mode Off 1: High Speed mode On
711-158 Position Adjustment for End Position during Invert
(x4 Pulse)
10 20 0.4581mm Initial value 31.1mm (450 pulse) +4.6mm (766 pulse) / -4.6mm (566 pulse) 10 pulse
increments
711-164 Slow Scan Original Size Correction Value 50 0~100 0.1mm Correction value for [Size Detection Auto-Correction Function] Original Size Correc-
tion Value: +/-5mm
711-200 Position Adjustment for Pre Regist End Position
(Original Lead Edge Eject Amount from Regi Roll
in x2 Pulse Increments)
8 0~16 0.6249mm Initial value 0mm (0 pulse) +5.0mm (80 pulse) / -5.0mm (-80 pulse) 10 pulse incre-
ments This value also applies to Scan Position Transport Time.
711-201 Position Adjustment for Feed Motor Off Start Posi-
tion (x3 Pulse)
8 1~15 0.6249mm Initial value 5.0mm (80 pulse) +4.4mm (150 pulse) / -4.4mm (10 pulse) 10 pulse
increments
711-202 Position Adjustment for Position to Start Increasing
Speed in Duplex (x5 Pulse)
10 0~20 0.4581mm Initial value 50.4mm (1080 pulse) +4.6mm (1180 pulse) / -4.6mm (980 pulse) 10
pulse increments
711-203 Position Adjustment for First-Out Pre Feed Posi-
tion in Duplex (x7 Pulse)
5 0~10 0.6835mm Initial value 14.6mm (224 pulse) +3.4mm (274 pulse) / -3.4mm (174 pulse) 10 pulse
increments
711-204 Position Adjustment for N.R. Solenoid On Position
during Invert Output (x8 Pulse)
10 0~20 0.4581mm Initial value 15.0mm (241 pulse) +4.6mm (341 pulse) / -4.6mm (141 pulse) 10 pulse
increments
711-205 Side2 Feed Motor Reverse Start Time Adjustment
Value (T1 ms)
4 0~20 4msec Initial value 0ms +80ms/-20ms, 4ms increments
711-207 Next Feed Start Time Adjustment Value (T3 ms) 5 2~27 4msec Initial value 0m +88ms/-12ms, 4ms increments
711-208 Simplex Next Pre Regist Start Time Adjustment
Value (T4 ms)
6 6~25 4msec Initial value 4ms +76ms/0ms, 4ms increments
711-209 Invert Start Time Adjustment Value (T6 ms) 5 0~25 4msec Initial value 0ms +80ms/-20ms, 4ms increments
711-210 N.R. Solenoid On Start Time Adjustment Value
during Invert Output (T7 ms)
5 0~15 4msec Initial value0ms +40ms/-20ms, 4ms increments
711-211 First-Out Original Feed Start Time Adjustment
Value (T8 ms)
5 0~25 4msec Initial value 0ms +80ms/-20ms, 4ms increments
711-212 Duplex Next Pre Regist Start Time Adjustment
Value (T9 ms)
6 6~25 4msec Initial value 4ms +76ms/0ms, 4ms increments
Table 2 CVT DADF NVM LIST
