Initialize NVM
Launch Version
General Procedures
SYS-System The following NVM locations will be initialized:
• Chain - Link 700 - 071, 075, 076, 078, 080 through 088, 127, 128, 368,
389, 390, 396, 398, 410 through 412
• Chain - Link 780 - 072, 073, 141, 145
• Chain - Link 790 - 003
• Chain - Link 800 - 018
• Chain - Link 810 - 130
• Chain - Link 820 - 003, 024, 026, 038 through 047, 052 through 054,
060 through 119, 121
• Chain - Link 823 - 042 through 047
• Chain - Link 830 - 081, 090
• Chain - Link 850 - 001 through 004, 007, 009 through 012, 015
through 018
• Chain - Link 870 - 010 through 045
SYS-User All user settable NVM locations in the following chains will be reset:
• Chain - Link 700 - 071, 075, 076, 078, 080 through 088, 368, 389, 390
Table 1 NVM Initialization
Name Description
