Xerox WorkCentre 5230 User Manual

February, 2008
2-104
WorkCentre 5225, 5230
012-211 (A-Finisher)
Launch Version
Status Indicator Raps
Enter [012-278]. Block and unblock the Stacker Stack Sensor 1 by rotating the actuator. The
display changes.
YN
Check the connections of P/J8707 and P/J8722. P/J8707 and P/J8722 are securely
connected.
YN
Connect P/J8707 and P/J8722 securely.
Check for an open or short circuit between J8707 and J8722. The wires between
J8707 and J8722 are OK.
YN
Repair the open or short circuit.
Measure the voltage between Finisher PWB J8707-6 (+) and GND (-). The voltage is
approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between Finisher PWB J8707-5 (+) and (-). Block and unblock the
Stacker Stack Sensor 1 by rotating the actuator.
The voltage changes.
YN
Replace the Stacker Stack Sensor 1 (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Enter [012-279]. Block and unblock the Stacker Stack Sensor 2 by rotating the actuator. The
display changes.
YN
Check the connections of P/J8707 and P/J8721. P/J8707 and P/J8721 are securely
connected.
YN
Connect P/J8707 and P/J8721 securely.
Check for an open or short circuit between J8707 and J8721. The wires between
J8707 and J8721 are OK.
YN
Repair the open or short circuit.
Measure the voltage between Finisher PWB J8707-3 (+) and GND (-). The voltage is
approx. +5VDC.
YN
Go to Wirenet A-Finisher +5VDC and check the +5VDC circuit.
Measure the voltage between Finisher PWB J8707-2 (+) and GND (-). Block and unblock
the Stacker Stack Sensor 2 by rotating the actuator.
The voltage changes.
YN
Replace the Stacker Stack Sensor 2 (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem
continues, replace the Finisher PWB (PL 22.7).
Enter [012-060] and [012-061] alternately. The Stacker Motor rotates.
YN
Check the connections of P/J8711 and P/J8736. P/J8711 and P/J8736 are securely
connected.
YN
Connect P/J8711 and P/J8736 securely.
Check for an open or short circuit between J8711 and P8736. The wires between
J8711 and P8736 are OK.
YN
Repair the open or short circuit.
Enter [012-060], measure the voltage between Finisher PWB J8711-1 (+) and GND (-).
The voltage changes.
YN
Go to Wirenet 7.2.38 A-Finisher +24VDC and check the +24VDC circuit. If the prob-
lem continues, replace the Finisher PWB (PL 22.7).
Enter [012-061], measure the voltage between Finisher PWB J8711-2 (+) and GND (-).
The voltage changes.
YN
Go to Wirenet A-Finisher +24VDC and check the +24VDC circuit. If the problem con-
tinues, replace the Finisher PWB (PL 22.7).
Check the wires and connectors for an intermittent open and short circuit. If the problem
continues, replace the Stacker Motor (PL 22.8).
Check the wires and connectors for an intermittent open or short circuit. If the problem contin-
ues, replace the Finisher PWB (PL 22.7).
A
B
B
