February, 2008
2-375
WorkCentre 5225, 5230
024-982 , 024-984
Status Indicator Raps
Launch Version
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8988-19 (+) and GND (-) (BSD 12.24).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8988-20 (+) and GND (-) (BSD 12.24).
Actuate the Stack Height Sensor with paper. The voltage changes.
YN
Replace the Stack Height Sensor 2 (PL 23.11).
Replace the Finisher PWB (PL 23.16).
Alternately execute Component Control[012-060 Stacker Motor up ON] and Component Con-
trol[012-061 Stacker Motor down ON]. The Stacker Motor (PL 23.7) starts up.
YN
Check the connections of P/J8986. P/J8986 are connected correctly.
YN
Connect P/J8986.
Check the wires on P8986 for an open circuit or a short circuit (BSD 12.24). The wires
on P8986 is conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Stacker Motor (PL 23.7). If the problem persists, replace the Finisher PWB
(PL 23.16).
Replace the Finisher PWB (PL 23.16). If the problem persists, replace the MCU PWB (PL 9.1).
024-984 Booklet Low Staple F
BSD-ON:12.26
Booklet Stapler Low Staple Front signal was detected just before Stapling operation.
Booklet Stapler Low Staple Front signal was detected at Power ON, at initialization, or when
the interlock was closed.
Procedure
Supply the staples. The problem is resolved.
YN
Enter Component Control [013-107 Front Low Staple Switch], Select Start. ‘LOW’ (sta-
ples available) is displayed
YN
Check the connections of J8894, P/J8995 and P/J8892. The connectors are
connected correctly.
YN
Connect the connectors.
Check the wire between J8894 and J8995 for an open circuit or a short circuit (BSD
12.24).
The wire between J8894 and J8995 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8995-7 (+) and GND (-) (BSD
12.26).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8894-1 (+) and GND (-) (BSD
12.26).
The voltage is approx. +5VDC.
YN
Replace the Front Low Staple Switch (PL 23.19).
Replace the Finisher PWB (PL 23.16).
Select Stop. Replace the Finisher PWB (PL 23.16). If the problem continues, replace the
Booklet PWB (PL 23.21).
If the problem continues, replace the Finisher PWB (PL 23.16). If the problem persists, replace
the Booklet PWB (PL 23.21).
A
