B.3 Parameter Table
364 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
b5-14
(1B2H)
PI Feedback Loss Detection Time
Sets a delay time for PI feedback loss.
Default: 1.0 s
Min: 0.0 s
Max: 25.5 s
151
b5-15
(1B3H)
PI Sleep Function Start Level
Sets the frequency level that triggers the sleep function.
Default: 0.0 Hz
Min: 0.0 Hz
Max: 200.0 Hz
152
b5-16
(1B4H)
PI Sleep Delay Time
Sets a delay time before the sleep function is triggered.
Default: 0.0 s
Min: 0.0 s
Max: 25.5 s
152
b5-17
(1B5H)
PI Accel/Decel Time
Sets the acceleration and deceleration time to PI setpoint.
Default: 0.0 s
Min: 0.0 s
Max: 6000.0 s
153
b5-18
(1DCH)
PI Setpoint Selection
0: Disabled
1: Enabled
Default: 0
Min: 0
Max: 1
153
b5-19
(1DDH)
PI Setpoint Value
Sets the PI target value when b5-18 = 1. Set as a percentage of the maximum output frequency.
Default: 0.00%
Min: 0.00%
Max: 100.00%
153
b5-20
(1E2H)
PI Setpoint Scaling
0: 0.01Hz units
1: 0.01% units (100% = max output frequency)
2: r/min (number of motor poles must entered)
3: User Defined (set scaling to b5-38 and b5-39)
Default: 1
Min: 0
Max: 3
153
b5-21
(1E3H)
PI Sleep Input Source
Input Source Selection for Sleep Function Mode
0: PI Setpoint
1: SFS Input
2: Snooze
Default: 1
Min: 0
Max: 2
154
b5-22
(1E4H)
PI Snooze Level
Sets the PI Snooze function start level as a percentage of maximum frequency.
Default: 0%
Min: 0%
Max: 100%
154
b5-23
(1E5H)
PI Snooze Delay Time
Sets the PI Snooze function delay time in terms of seconds.
Default: 0 s
Min: 0 s
Max: 2600 s
154
b5-24
(1E6H)
PI Snooze Deactivation Level
When the PI feedback drops below this level, normal operation starts again. Sets as a percentage
of maximum frequency.
Default: 0%
Min: 0%
Max: 100%
154
b5-25
(1E7H)
PI Set
point Boost Setting
Tempor
ary increase of PI setpoint to create an overshoot of the intended PI setpoint
Default: 0%
Min: 0%
Max: 100%
154
b5-26
(1E8H)
PI Maximum Boost Time
Sets maximum boost time when PI feedback does not reach Boost level. Snooze function starts
when PI feedback exceeds Boost setting level or boost time expired.
Default: 0 s
Min: 0 s
Max: 2600 s
154
b5-27
(1E9H)
PI Snooze Feedback Level
PI Snooze mode will be activated when PI feedback is above this level. Sets as a percentage of
maximum frequency.
Default: 60%
Min: 0%
Max: 100%
154
b5-28
(1EAH)
PI Feedback Function Selection
0: Disabled
1: Square Root
Default: 0
Min: 0
Max: 1
155
b5-29
(1EBH)
PI Square Root Gain
A multi-plier applied to the square root of the feedback.
Default: 0.00
Min: 0.00
Max: 2.00
155
b5-30
(1ECH)
PI Feedback Offset
PI feedback offset. Sets as a percentage of maximum frequency.
Default: 0.00%
Min: 0.00%
Max: 100.00%
155
b5-34
(19FH)
PI Output Lower Limit
Sets the minimum output possible from the PI controller as a percentage of the maximum output
frequency.
Default: 0.0%
Min: -100.0%
Max: 100.0%
155
b5-35
(1A0H)
PI Input Limit
Limits the PI control input (deviation signal) as a percentage of the maximum output frequency.
Acts as a bipolar limit.
Default: 1000.0%
Min: 0.0%
Max: 1000.0%
155
b5-36
(1A1H)
PI Feedback High Detection Level
Sets the PI feedback high detection level as a percentage of the maximum output frequency.
Default: 100%
Min: 0%
Max: 100%
151
b5-37
(1A2H)
PI Feedback High Detection Time
Sets the PI feedback high level detection delay time.
Default: 1.0 s
Min: 0.0 s
Max: 25.5 s
151
b5-38
(1FEH)
PI Setpoint User Display
Sets the display value of U5-01 and U5-04 when the maximum frequency is output.
Default:
<5>
Min: 1
Max: 60000
155
