B.3 Parameter Table
Parameter List
B
YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual 365
■ b8: Energy Saving
b5-39
(1FFH)
PI Setpoint Display Digits
0: No decimal places
1: One decimal places
2: Two decimal places
3: Three decimal places
Default:
<5>
Min: 0
Max: 3
155
b5-40
(17FH)
Frequency Reference Monitor
Content During PI 0: Frequency Reference (U1-01) After PI
1: Frequency Reference (U1-01)
Default: 0
Min: 0
Max: 1
155
b5-41
(160H)
PI Unit Selection
0: WC (Inch of Water)
1: PSI (ib/Sq inch)
2: GPM (Gallons/min)
3: F (Deg Fahrenheit)
4: CFM (Cubic ft/min)
5: CMH (Cubic M/h)
6: LPH (Liters/h)
7: LPS (Liters/s)
8: Bar (Bar)
9: Pa (Pascals)
10: C (Deg Celsius)
11: Mtr (Meters)
12: Ft (Feet)
13: LPN (Liters/min)
14: CMM (Cubic M/min)
Default: 0
Min: 0
Max: 14
156
b5-42
(161H)
PI Output Monitor Calculation
Method
0: Linear unit
1: Square root unit
2: Quadratic unit
3: Cubic unit
Default: 0
Min: 0
Max: 3
157
b5-43
(162H)
Custom PI Output Monitor
Setting 1
U5-14, U5-15 show Custom PI output. U5-14 shows the upper 4digits and U5-15 shows the
lower 4 digits.
It shows 999999.99 maximum. b5-43 and b5-44 is used for setting maximum monitor value at
maximum frequency.
Default: 0
Min: 0
Max: 9999
157
b5-44
(163H)
Custom PI Output Monitor
Setting 2
Default: 0.00
Min: 0.00
Max: 99.99
157
b5-45
(164H)
Custom PI Output Monitor
Setting 3
b5-07,-08 show Custom PI output.b5-45 is used for setting the minimum display value at o
speed. This function can be effective when b5-42 is set to 1 (Linear unit)
Default: 0.0
Min: 0.0
Max: 999.9
157
b5-46
(165H)
PI Setpoint Monitor Unit Selection
0: WC (Inch of Water)
1: PSI (ib/Sq inch)
2: GPM (Gallons/min)
3: F (Deg Fahrenheit)
4: CFM (Cubic ft/min)
5: CMH (Cubic M/h)
6: LPH (Liters/h)
7: LPS (Liters/s)
8: Bar (Bar)
9: Pa (Pascals)
10: C (Deg Celsius)
11: Mtr (Meters)
12: Ft (Feet)
13: LPN (Liters/min)
14: CMM (Cubic M/min)
Default: 0
Min: 0
Max: 14
157
b5-47
(17DH)
Reverse Operation Selection 2 by
PI Output
Reverse operation selection when b5-01 = 3 or 4.
0: Zero limit when PI output is a negative value.
1:Reverse operation when PI output is a negative value
(Zero limit if the reverse operation is prohibited by b1-04).
Default: 1
Min: 0
Max: 1
158
<5> Default setting is dependent on PI setpoint scaling (b5-20).
No.(Addr.) Name Description Setting Page
b8-01
(1CCH)
Energy Saving Control Selection
0: Disabled
1: Enabled
Default:
<10>
Min: 0
Max: 1
158
b8-04
(1CFH)
Energy Saving Coefficient Value
Determines the level of maximum motor efficiency. Setting range is 0.0 to 2000.0 maximum
output up to 3.7 kW. Refer to Model Number and Nameplate Check on page 29.
Default:
<8> <9>
Min: 0.00
Max: 655.00
158
b8-05
(1D0H)
Power Detection Filter Time
Sets a time constant filter for output power detection.
Default: 20 ms
Min: 0 ms
Max: 2000 ms
159
No.(Addr.) Name Description Setting Page
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
OLV/PMV/f
common_
TMonly
