B.3 Parameter Table
370 YASKAWA ELECTRIC SIEP C710616 35D YASKAWA AC Drive E1000 Technical Manual
■ E5: PM Motor Settings
E2-11
(318H)
Motor Rated Power
Sets the motor rated power in kilowatts (1 HP = 0.746 kW). Automatically set during
Auto-Tuning.
Note: This value’s number of decimal places depends on the motor capacity. The value will
have two decimal places (0.01 kW) when using the motor less than 300 kW and one decimal
place (0.1 kW) when using the motor higher than 300 kW.
Default:
<9>
Min: 0.00 kW
Max: 650.00 kW
176
<9> Default setting value is dependent on the drive model (o2-04).
<19> This value's number of decimal places depends on the drive model. The value will have two decimal places (0.01 A) if the drive model is
CIMR-E2A0004 to 2A0040, 4A0002 to 4A0023 and one decimal place (0.1 A) if the drive model is CIMR-E2A0056 to 2A0415, 4A0031
to 4A1200.
No.(Addr.) Name Description Setting Page
E5-01
(329H)
<3>
<3> Parameter setting value is not reset to the default value when the drive is initialized.
<4> Default setting is dependent on the control mode (A1-02), the drive model (o2-04).
<14> Default setting value is dependent on the motor code set to E5-01.
<19> This value's number of decimal places depends on the drive model. The value will have two decimal places (0.01 A) if the drive model is
CIMR-E2A0004 to 2A0040, 4A0002 to 4A0023 and one decimal place (0.1 A) if the drive model is CIMR-E2A0056 to 2A0415, 4A0031
to 4A1200.
<23> If using a Yaskawa SMRA Series SPM Motor, the default setting is 1800 r/min.
<28> Selection may vary depending on the motor code entered to E5-01.
<51> This parameter is valid from the drive software version S3801 and later.
Motor Code Selection
Enter the Yaskawa motor code for the PM motor being used. Various motor parameters are
automatically set based on the value of this parameter. Setting that were changed manually will
be overwritten by the defaults of the selected motor code.
Note: Set to FFFF when using a non-Yaskawa PM motor or a special motor.
Default:
<4> <23>
Min: 0000
Max: FFFF
<28>
177
E5-02
(32AH)
<3>
Motor Rated Power
Sets the rated capacity of the motor.
Note: This value’s number of decimal places depends on the motor capacity. The value will
have two decimal places (0.01 kW) when using the motor less than 300 kW and one decimal
place (0.1 kW) when using the motor higher than 300 kW.
Default:
<14>
Min: 0.10 kW
Max: 650.00 kW
177
E5-03
(32BH)
<3>
Motor Rated Current
Sets the motor rated current.
Default:
<14>
Min: 10% of drive rated
current
Max: 200% of drive
rated current
<19>
177
E5-04
(32CH)
<3>
Number of Motor Poles
Sets the number of motor poles.
Default:
<14>
Min: 2
Max: 48
177
E5-05
(32DH)
<3>
Motor Stator Resistance
Set the resistance for each motor phase.
Default:
<14>
Min: 0.000 Ω
Max: 65.000 Ω
178
E5-06
(32EH)
<3>
Motor d-Axis Inductance
Sets the d-axis inductance for the PM motor.
Default:
<14>
Min: 0.00 mH
Max: 300.00 mH
178
E5-07
(32FH)
<3>
Motor q-Axis Inductance
Sets the q-axis inductance for the PM motor.
Default:
<14>
Min: 0.00 mH
Max: 600.00 mH
178
E5-09
(331H)
<3>
Motor Induction Voltage Constant
1
Set the induced phase peak voltage in units of 0.1 mV (rad/s) [electrical angle]. Set this
parameter when using a Yaskawa SSR1 Series PM motor with derated torque.
When setting this parameter, E5-24 should be set to 0.
Default:
<14>
Min: 0.0 mV/(rad/s)
Max:
2000.0 mV/(rad/s)
178
E5-24
(353H)
<3>
Motor Induction Voltage Constant
2
Set the induced phase-to-phase rms voltage in units of 0.1 mV/(r/min) [mechanical angle]. Set
this parameter when using a Yaskawa SMRA Series SPM motor.
When setting this parameter, E5-09 should be set to 0.
Default:
<14>
Min: 0.0 mV/(r/min)
Max: 6500.0 mV/(r/
min)
178
E5-25
(35EH)
<51>
Polarity Judge Selection
0: Positive Polarity
1: Negative Polarity
Default: 0
Min: 0
Max: 1
178
