i.1 Preface
Yaskawa manufactures products used as components in a wide variety of industrial systems and equipment. The selection
and application of Yaskawa products remain the responsibility of the equipment manufacturer or end user. Yaskawa accepts
no responsibility for the way its products are incorporated into the final system design. Under no circumstances should
any Yaskawa product be incorporated into any product or design as the exclusive or sole safety control. Without exception,
all controls should be designed to detect faults dynamically and fail safely under all circumstances. All systems or
equipment designed to incorporate a product manufactured by Yaskawa must be supplied to the end user with appropriate
warnings and instructions as to the safe use and operation of that part. Any warnings provided by Yaskawa must be promptly
provided to the end user. Yaskawa offers an express warranty only as to the quality of its products in conforming to
standards and specifications published in the Yaskawa manual. NO OTHER WARRANTY, EXPRESS OR IMPLIED, IS
OFFERED. Yaskawa assumes no liability for any personal injury, property damage, losses, or claims arising from
misapplication of its products.
This manual is designed to ensure correct and suitable application of Variable V1000-Series drives. Read this manual
before attempting to install, operate, maintain, or inspect a drive and keep it in a safe, convenient location for future
reference. Be sure you understand all precautions and safety information before attempting application.
u
Applicable Documentation
The following manuals are available for V1000 series drives:
V1000 Series AC Drive Quick Start Guide
Read this manual first. This guide is packaged together with the product. It contains basic
information required to install and wire the drive. This guide provides basic programming and
simple setup and adjustment.
V1000 Series AC Drive Technical Manual
This manual describes installation, wiring, operation procedures, functions, troubleshooting,
maintenance, and inspections to perform before operation.
u
Symbols
Note: Indicates a supplement or precaution that does not cause drive damage.
Indicates a term or definition used in this manual.
u
Terms and Abbreviations
• Drive: Yaskawa V1000 Series Drive
• PM motor: Permanent Magnet Synchronous Motor (an abbreviation for IPM motor or SPM motor)
• IPM motor: Interior Permanent Magnet Motor (e.g., Yaskawa SSR1 Series motor)
• SPM motor: Surface Mounted Permanent Magnet Motor (e.g., Yaskawa SMRA Series SPM motor)
• PG: Pulse Generator
• r/min: Revolutions per Minute
• V/f: V/f Control
• OLV: Open Loop Vector Control
• OLV/PM: Open Loop Vector Control for PM
