D.2 European Standards
Figure D.1 CE Mark
The CE mark indicates compliance with European safety and environmental regulations and is required for engaging in
business and commerce in Europe.
European standards include the Machinery Directive for machine
manufacturers, the Low Voltage Directive for electronics
manufacturers and the EMC guidelines for controlling noise.
This drive displays the CE mark based on the EMC guidelines and the Low Voltage Directive.
• Devices used in combination with this drive must also be CE certified and display the CE mark. When using drives
displaying the CE mark in combination with other devices, it is ultimately the responsibility of the user to ensure
compliance with CE standards. After setting up the device, verify that conditions meet European standards.
• Low Voltage Directive: 73/23/EEC, 93/68/EEC
u
CE Low Voltage Directive Compliance
This
drive
has
been
tested
according
to
European
standard IEC/EN 61800-5-1, and it fully complies with the Low Voltage
Directive.
To comply with the Low Voltage Directive, be sure to meet the following conditions when combining this drive with other
devices:
n
Area of Use
Do not use drives in areas with pollution higher than severity 2 and overvoltage category 3 in accordance with IEC/EN
664.
n
Factory Recommended Branch Circuit Protection
Yaskawa recommends installing one of the following types of branch circuit protection to maintain compliance with
UL508C. Semiconductor protective type fuses are preferred. Alternate branch circuit protection devices are also listed in
Table D.1.
NOTICE: If a fuse is blown or an Earth Leakage Circuit Breaker (ELCB) is tripped, check the wiring and the selection of peripheral
devices to identify the cause. Contact Yaskawa before restarting the drive or the peripheral devices if the cause cannot be identified.
Table D.1 Factory Recommended Drive Branch Circuit Protection
Drive Model
Fuse Type
Manufacturer: Bussmann
Model Fuse Ampere Rating (A)
Single-Phase 200 V Class
BA0001 FWH-25A14F 25
BA0002 FWH-25A14F 25
BA0003 FWH-60B 60
BA0006 FWH-80B 80
BA0010 FWH-100B 100
BA0012 FWH-125B 125
BA0018 FWH-175B 175
Three-Phase 200 V Class
2A0001 FWH-25A14F 25
2A0002 FWH-25A14F 25
2A0004 FWH-25A14F 25
2A0006 FWH-25A14F 25
2A0008 FWH-70B 70
2A0010 FWH-70B 70
2A0012 FWH-70B 70
2A0018 FWH-90B 90
2A0020 FWH-90B 90
2A0030 FWH-100B 100
D.2 European Standards
434
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
