YASKAWA V1000 Technical Manual

4.4 Start-up Flowcharts
The flowcharts in this section summarize basic steps required to start the drive. Use the flowcharts to determine the most
appropriate start-up method for a given application. The charts are intended as a quick reference to help familiarize the
user with start-up procedures.
Flowchart Subchart Objective Page
A Basic startup procedure and motor tuning. 89
A-1 Simple motor setup with Energy Savings or Speed Search using V/f mode. 90
A-2 High-performance operation using Open Loop Vector (OLV) motor control. 91
A-3 Operation with Permanent Magnet (PM) motors. 92
-
Setup of drive using application specific selections. Refer to Application Selection on page
94.
-
4.4 Start-up Flowcharts
88
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
