B.3 Control Mode Dependent Parameter Default Values
The tables below list parameters that depend on the control mode selection (A1-02 for motor 1, E3-01 for motor 2). These
parameters are initialized to the shown values if the control mode is changed.
u
A1-02 (Motor 1 Control Mode) Dependent Parameters
Table B.1 A1-02 (Motor 1 Control Mode) Dependent Parameters and Default Values
Parameter Description Setting Range Resolution
Control Modes (A1-02)
V/f (0) OLV (2) PM (5)
b3-02 Speed Search deactivation current 0 to 200 1% 120 100
b3-08
Current Control Gain during Speed Search (Speed
Estimation Type)
0.00 to 6.00
0.50
<1>
0.50
<1>
0.30
b8-02 Energy Saving gain 0.0 to 10.0 0.1 0.7
C2-01 S-curve time at acceleration start 0.00 to 10.00 0.01 s 0.20 0.20 1.00
C3-01 Slip compensation gain 0.0 to 2.5 0.1 0.0 1.0
C3-02 Slip compensation time constant 0 to 10000 1 ms 2000 200
C4-01 Torque compensation gain 0.00 to 2.50 0.01 1.00 1.00 0.00
C4-02 Torque comp. primary delay time 0 to 10000 1 ms 200 20 100
C6-02 Carrier frequency 1 to F 1
7
<1>
7
<1>
2
E1-04 Maximum output frequency 40.0 to 400.0 0.1 Hz
60.0
<4>
60.0
<4>
<3>
E1-05
Maximum output voltage
<2>
0.0 to 255.0 0.1 V 200.0 200.0
<3>
E1-06 Base Frequency 0.0 to 400.0 0.1 Hz
60.0
<4>
60.0
<4>
<3>
E1-07 Middle output frequency 0.0 to 400.0 0.1 Hz
3.0
<4>
3.0
<4>
E1-08
Middle output freq. voltage
<2>
0.0 to 255.0 0.1 V 16.0 12.0
E1-09 Minimum output frequency 0.0 to 400.0 0.1 Hz
1.5
<4>
0.5
<4>
<3>
E1-10
Minimum output voltage
<2>
0.0 to 255.0 0.1 V 12.0 2.5
E1-11 Middle output frequency 2 0.0 to 400.0 0.1 Hz 0.0 0.0
E1-12
Middle output freq. voltage 2
<2>
0.0 to 255.0 0.1 V 0.0 0.0
E1-13
Base voltage
<2>
0.0 to 255.0 0.1 V 0.0 0.0
L1-01 Motor protection selection 0 to 4 1 1 4
L3-20 Main power circuit voltage adjustment gain 0.00 to 5.00 0.01 1.00 0.30 0.65
L3-21 Accel/decel rate calculation gain 0.00 to 200.00 0.01 1.00 1.00 2.50
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
<2> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<3> Default setting value is dependent on parameter E5-01, Motor Code Selection.
<4>
The default value is for the following localized drives: Japan (Model code: CIMR-VAoA) and Asia (Model code: CIMR-VToA) .Refer to
China Localized Drive Default Values on page 381
for the default values of China localized (Model code: CIMR-VBoA) drives.
B.3 Control Mode Dependent Parameter Default Values
378
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
