No. Parameter Name Default Setting
H2-02 Terminals P1 Function Selection 37: During Frequency Output
H2-03 Terminals P2 Function Selection 5: Frequency Detection 2
L2-03 Momentary Power Loss Minimum Baseblock Time 0.3 s
L3-04 Momentary Power Loss Voltage Recovery Ramp Time 0: Disabled
L4-01 Speed Agreement Detection Level 2.0 Hz
L4-02 Speed Agreement Detection Width 0.0 Hz
L6-01 Torque Detection Selection 1 8: UL3 at RUN - Fault
L6-02 Torque Detection Level 1 5%
L6-03 Torque Detection Time 1 0.5 s
L8-05 Input Phase Loss Protection Selection
1: Enabled
<1>
L8-07 Output Phase Loss Protection Selection 1: Enabled
L8-38 Carrier Frequency Reduction 1: Enabled below 6 Hz
L8-41 High Current Alarm Selection 1: Enabled (alarm is output)
<1> Disable L8-05 for single-phase models.
Table 4.16 Hoist: User Parameters (A2-01 to A2-16):
No. Parameter Name No. Parameter Name
A1-02 Control Method Selection d1-02 Frequency Reference 2
b1-01 Frequency Reference Selection 1 d1-03 Frequency Reference 3
b6-01 Dwell Reference at Start E1-08 Middle Output Frequency Voltage
b6-02 Dwell Time at Start H2-01 Terminals MA, MB, and MC Function Selection
C1-01 Acceleration Time 1 L1-01 Motor Overload Protection Selection
C1-02 Deceleration Time 1 L4-01 Speed Agreement Detection Level
C6-02 Carrier Frequency Selection L6-02 Torque Detection Level 1
d1-01 Frequency Reference 1 L6-03 Torque Detection Time 1
u
Notes on Controlling the Brake when Using the Hoist Application Preset
Preventing Inadvertent Brake Release by Disabling Frequency Detection During a Baseblock Condition
The frequency detection function is used for controlling the brake.
Although the drive output will be shut off, the drive will maintain the frequency reference if an external Baseblock
command is given (H1-xx = 8/9) and the
Run command remains active. Disable the Frequency detection during Baseblock
by setting parameter L4-07 = “0” to prevent the brake remaining open during Baseblock condition.
Brake Control During Safe Disable Input
If the Safe Disable input is released, the drive output will shut off and the frequency reference will reset to 0 and the brake
will close, regardless if the Run command is active. The Run command must be cycled before the drive can restart.
The table below shows how to set up the drive when using output terminals P2-PC as brake control output.
Function Parameter Setting V/f OLV OLV for PM
Frequency Detection 2
Digital Output (Brake Control)
H2-03 5 O O O
Frequency Detection
during Baseblock
L4-07 0 O O O
Frequency Detection Level
(Brake Open Frequency)
L4-01
1.0 to 3.0 Hz
<1>
O O O
Frequency Detection Width
(Brake Close Bandwidth)
L4-02
0.0 to 0.5 Hz
<2>
O O O
<1> This is the setting recommended when using Open Loop Vector Control. In V/f Control, set the level as the motor rated slip frequency plus
0.5 Hz. Not enough motor torque will be
created if this value is set too low, and the load may tend to slip. Make sure this value is greater than
the minimum output frequency and greater than the value of L4-02 as shown in the diagram below. If set too high, however, there may be a
jolt at start.
<2> Hysteresis for Frequency Detection 2 can be adjusted by changing the Frequency Detection Width (L4-02) between 0.0 and 0.5 Hz. If the load
slips during stop, make changes in steps of 0.1 Hz until the load no longer slips.
4.6 Application Selection
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
97
