Setting 0: Disabled
A Run command is not accepted while the digital operator is in Programming Mode.
Setting 1: Enabled
A Run command is accepted in any digital operator mode.
Setting 2: Prohibit Programming During Run
It is not possible to enter the Programming Mode as long as the drive output is active.
n
b1-14: Phase Order Selection
Sets the phase order for drive output terminals U/T1, V/T2, and W/T3.
No. Parameter Name Setting Range Default
b1-14 Phase Order Selection 0 or 1 0
Setting 0: Standard Phase Order
Setting 1: Switched Phase Order
n
b1-15: Frequency Reference Selection 2
Refer to b1-01: Frequency Reference Selection 1
on page 117 for details.
The value set to b1-15 is
used as Frequency Reference 2 when one of the multi-function input terminals set for Frequency
Reference Switching (H1-oo = 2) closes. Refer to Setting 2: External Reference 1/2 Selection on page 177 for
instructions on how this function works.
No. Parameter Name Setting Range Default
b1-15 Frequency Reference Selection 2 0 to 4 0
n
b1-16: Run Command Selection 2
Refer to b1-02: Run Command Selection 1 on page 119 for details.
The
value set to b1-16 is used as
Run Command Source 2 when one of the multi-function input terminals set for Frequency
Reference Switching (H1-oo = 2) closes. Refer to Setting 2: External Reference 1/2 Selection on page 177 for
instructions on how this function works.
No. Parameter Name Setting Range Default
b1-16 Run Command Selection 2 0 to 3 0
n
b1-17: Run Command at Power Up
This parameter is used to determine whether an external Run command that is active during power up of the drive will
start the drive or not.
No. Parameter Name Setting Range Default
b1-17 Run Command at Power Up 0 or 1 0
Setting 0: Run Command at Power Up is not Issued
The Run command has to be cycled to start the drive.
Note: For
safety
reasons,
the
drive
is
initially
set
up not to accept a Run command at power up (b1-17 = "0"). If a Run command is issued at
power up, the RUN indicator LED will flash quickly. Change parameter b1-17 to 1 if a Run command active at power up shall be
accepted by the drive.
Setting 1: Run Command and Power Up is Issued
An external Run command active during power up is issued and the drive starts to operate the motor as soon as it gets
ready for operation (i.e. once the internal start up process is complete).
WARNING! Sudden Movement Hazard. If b1-17 is set to 1 and an external Run command is active during power up, the motor will
begin rotating as soon as the power is switched on. Proper precautions must be taken to ensure that the area around the motor is safe
prior to powering up the drive. Failure to comply may cause serious injury.
u
b2: DC Injection Braking
These parameters determine how the DC Injection Braking/Short Circuit Braking feature operates. Parameters involving
the starting frequency, current level, braking time are located here.
n
b2-01: DC Injection Braking Start Frequency
Active when “Ramp to Stop” is selected as the stopping method (b1-03 = 0). Sets the starting frequency for:
•
DC Injection Braking at stop in V/f and OLV control.
5.2 b: Application
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
123
5
Parameter Details
