B.1 Parameter Groups
Parameter
Group
Name Page
A1 Initialization 331
A2 User Parameters 332
b1 Operation Mode Selection 332
b2 DC Injection Braking 333
b3 Speed Search 333
b4 Delay Timer 334
b5 PID Control 334
b6 Dwell Function 336
b8 Energy Saving 336
C1 Acceleration/Deceleration Time 337
C2 S-Curve Accel/Decel 337
C3 Motor Slip Compensation 337
C4 Motor Torque Compensation 338
C5 Speed Control (ASR) 338
C6 Carrier Frequency 338
d1 Frequency Reference 340
d2 Reference Limits 340
d3 Jump Frequencies 340
d4 Frequency Reference Hold 341
d7 Off-Set Frequency 341
E1 V/f Pattern 342
E2 Motor Setup 342
E3 Motor 2 V/f Pattern 343
E4 Motor Setup 2 344
E5 PM Motor Setup 345
F1 Fault Detection during PG Speed Control 347
F6 Network Communications 347
H1 Digital Inputs 350
H2 Digital Outputs 352
H3 Analog Inputs 354
Parameter
Group
Name Page
H4 Analog Outputs 355
H5 Serial Communications Setup 356
H6 Pulse Train I/O Setup 356
L1 Motor Overload 357
L2 Power Loss Ride-Thru 358
L3 Stall Prevention 358
L4 Reference Detection 360
L5 Fault Restart 360
L6 Overtorque Detection 361
L7 Torque Limit 362
L8 Hardware Protection 362
n1 Hunting Prevention 365
n2 Speed Feedback Detection 365
n3 High-Slip Braking 365
n6
Motor Line-to-Line Resistance Online
Tuning
365
n8 PM Motor Control 366
o1 Monitor Display Selection 367
o2 Operator Keypad Functions 367
o4 Maintenance Functions 368
q DWEZ Parameters 369
r DriveWorksEZ Connection 369
T1 Auto-Tuning 370
U1 Status Monitor 371
U2 Fault Trace 373
U3 Fault History 374
U4 Maintenance Monitor 374
U5 PID Monitor 376
U6 Control Monitor 376
U8 Custom Monitors for DriveWorksEZ 376
B.1 Parameter Groups
330
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
