Page #336 background imageLoading...
Page #336 background image
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
b5-40
<8>
Frequency Reference
Monitor Content during PID
0: Display the frequency reference (U1-01) after PID
compensation has been added.
1: Display the frequency reference (U1-01) before PID
compensation has been added.
0, 1 0 A A A 17F 138
b5-47
<5>
Reverse Operation Selection
2 by PID Output
Reverses operation selection when b5-01 = 3 or 4
0: Zero limit when PID output is a negative value
1: Reverse operation when PID output is a negative value
(Zero limit if the reverse operation is prohibited by b1-04)
0, 1 1 A A A 17D 139
b6: Dwell Function
Use b6 parameters to configure dwell function operation.
b6-01 Dwell Reference at Start
The Dwell function is used to temporarily hold the frequency
when driving a motor with a heavy load.
Parameters b6-01 and b6-02 set the frequency to hold and
the time to maintain that frequency at start.
Parameters b6-03 and b6-04 set the frequency to hold and
the time to maintain that frequency at stop.
b6-01
b6-02
b6-03
b6-04
OFF
Run command
Output
Frequency
Time
ON
0.0 to
400.0
0.0
Hz
A A A 1B6 139
b6-02 Dwell Time at Start
0.0 to
10.0
0.0 s A A A 1B7 139
b6-03 Dwell Frequency at Stop
0.0 to
400.0
0.0
Hz
A A A 1B8 139
b6-04 Dwell Time at Stop
0.0 to
10.0
0.0 s A A A 1B9 139
b8: Energy Saving
Use b8 parameters to configure the energy saving/conservation drive function.
b8-01
Energy Saving Control
Selection
Selects the Energy Savings function.
0: Disabled
1: Enabled
0, 1 0 A A 1CC 140
b8-02
<6>
Energy Saving Gain
Sets energy savings control gain when in Open Loop Vector
Control.
0.0 to
10.0
0.7 A 1CD 140
b8-03
<6>
Energy Saving Control Filter
Time Constant
Sets energy saving control filter time constant when in Open
Loop Vector Control.
0.00 to
10.00
0.50
<4>
A 1CE 140
b8-04
Energy Saving Coefficient
Value
Sets the Energy Saving coefficient and is used to fine
adjustments in V/f Control.
0.0 to
655.00
<9>
<10>
A 1CF 140
b8-05
Power Detection Filter Time Sets a filter time for the Power Detection used by Energy
Savings in V/f Control.
0 to 2000 20 ms A 1D0 140
b8-06
Search Operation Voltage
Limit
Sets the limit for the voltage search operation performed by
Energy Savings in V/f Control. Set as a percentage of the
motor base voltage. Disabled when set to 0%.
0 to 100 0% A 1D1 140
<1> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for A1-02 = 2-OLV control.
<2> A coasting motor may require a braking resistor circuit to bring the motor to a stop in the required time.
<3> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for A1-02 = 0-V/f Control.
<4> Default setting value is dependent on parameter o2-04, Drive Model Selection.
<5> Available in drive software versions PRG: 1020 and later.
<6> Parameter can be changed during Run.
<7> Default setting is dependent on parameter b5-20, PID Setpoint Scaling.
<8> Available in drive software versions PRG: 1014 and later.
<9>
Default setting value is dependent on parameter o2-04, Drive Model Selection and C6-01, Drive Duty Selection.
<10> Parameter value is changed if E2-11 is manually changed or changed by Auto-Tuning.
<11> Available in drive software versions PRG: 1022 and later.
<12> Default setting is determined by A1-02, Control Method Selection
B.2 Parameter Table
336
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
