E3-01 (Motor 2 Control Mode) Dependent Parameters
Table B.2 E3-01 (Motor 2 Control Mode) Dependent Parameters and Default Values
Parameter Description Setting Range Resolution
Control Modes (E3-01)
V/f (0) OLV (2)
E3-04 Maximum output frequency 40.0 to 400.0 0.1 Hz
60.0
<2>
60.0
<2>
E3-05
Maximum output voltage
<1>
0.0 to 255.0 0.1 V 200.0 200.0
E3-06 Base Frequency 0.0 to 400.0 0.1 Hz
60.0
<2>
60.0
<2>
E3-07 Middle output frequency 0.0 to 400.0 0.1 Hz
3.0
<2>
3.0
<2>
E3-08
Middle output freq. voltage
<1>
0.0 to 255.0 0.1 V 16.0 12.0
E3-09 Minimum output frequency 0.0 to 400.0 0.1 Hz 1.5 0.5
E3-10
Minimum output voltage
<1>
0.0 to 255.0 0.1 V
12.0
<2>
2.5
<2>
E3-11 Middle output frequency 2 0.0 to 400.0 0.1 Hz 0.0 0.0
E3-12
Middle output freq. voltage 2
<1>
0.0 to 255.0 0.1 V 0.0 0.0
E3-13
Base voltage
<1>
0.0 to 255.0 0.1 V 0.0 0.0
E3-14 Motor 2 Slip compensation gain 0.0 to 2.5 0.1 0.0 1.0
<1> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<2>
The default value is for the following localized drives: Japan (Model code: CIMR-VAoA) and Asia (Model code: CIMR-VToA) .Refer to
China Localized Drive Default Values
on page 381 for the default values of China localized (Model code: CIMR-VBoA) drives.
B.3 Control Mode Dependent Parameter Default Values
