B.6 Defaults by Drive Model and Duty Rating (ND/HD)
Table B.6 Single-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Settings
No. Description Unit Default Settings
− Model − BA0001 BA0002 BA0003
o2-04 Drive Model Selection Hex 30 31 32
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND
0 1 0 1 0 1
E2-11
(E4-11,
T1-02)
Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75
b3-06 Speed Search current 1 − 1 1 1 1 1 1
b3-08
Current Control Gain during Speed
Search (Speed Estimation Type)
– 0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy saving coefficient − 481.7 356.9 356.9 288.2 288.2 223.7
C6-02 Carrier frequency − 4 7 4 7 4 7
E2-01
(E4-01, T1-04)
Motor rated current A 0.6 1.1 1.1 1.9 1.9 3.3
E2-02
(E4-02)
Motor rated slip Hz 2.5 2.6 2.6 2.9 2.9 2.5
E2-03
(E4-03)
Motor no-load current A 0.4 0.8 0.8 1.2 1.2 1.8
E2-05
(E4-05)
Motor line-to-line resistance Ω 35.98 20.56 20.56 9.84 9.842 5.156
E2-06
(E4-06)
Motor leakage inductance % 21.6 20.1 20.1 18.2 18.2 13.8
E2-10
(E4-10)
Motor Iron Loss W 6 11 11 14 14 26
E5-01 Motor code hex FFFF FFFF FFFF FFFF 0002 0002
L2-02
Momentary power loss ride-through
time
s 0.1 0.1 0.1 0.1 0.1 0.1
L2-03 Mom. power loss Baseblock time s 0.2 0.2 0.2 0.2 0.2 0.3
L2-04
Momentary power loss voltage
recovery time
s 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Uv detection voltage V dc 160 160 160 160 160 160
L3-24 Motor acceleration time s 0.178 0.178 0.178 0.178 0.178 0.142
L8-02 Overheat alarm level °C 115 115 115 115 110 110
L8-09 Ground fault selection − 0 0 0 0 0 0
L8-35 Installation method selection − 0 0 0 0 0 0
L8-38 Carrier freq. reduction sel. − 1 1 1 1 1 1
n1-03 Hunting Prev. Time Const. ms 10 10 10 10 10 10
n2-01
Speed Feedback Detection Control
(AFR) Gain
– 1.00 1.00 1.00 1.00 1.00 1.00
B.6 Defaults by Drive Model and Duty Rating (ND/HD)
382
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
