B.4 V/f Pattern Default Values
The tables below show the V/f pattern settings default values depending on the control mode (A1-02) and the V/f pattern
selection (E1-03 in V/f Control).
Table B.3 E1-03 V/f Pattern Settings for Drive Capacity: Models BA0001 to BA0010,
2A0001 to 2A0010, and 4A0001 to 4A0005
No. Unit V/f Control
OLV
E1-03 − 0 1 2 3 4 5 6 7 8 9 A B C D E F
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120 180
60.0
<2>
60.0
<2>
E1-05
<1>
V 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0
60.0
<2>
60.0
<2>
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0
3.0
<2>
3.0
<2>
E1-08
<1>
V 16.0 16.0 16.0 16.0 35.0 50.0 35.0 50.0 19.0 24.0 19.0 24.0 16.0 16.0 16.0 16.0 12.0
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5
1.5
<2>
0.5
<2>
E1-10
<1>
V 12.0 12.0 12.0 12.0 8.0 9.0 8.0 9.0 12.0 13.0 12.0 15.0 12.0 12.0 12.0 12.0 2.5
<1> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<2>
The default value is for the following localized drives: Japan (Model code: CIMR-VAoA) and Asia (Model code: CIMR-VToA) .Refer to
China Localized Drive Default Values
on page 381 for the default values of China localized (Model code: CIMR-VBoA) drives.
Table B.4 E1-03 V/f Pattern Settings for Drive Capacity: Models BA0012 to BA0018,
2A0012 to 2A0069, and 4A0007 to 4A0038
No. Unit V/f Control
OLV
E1-03 − 0 1 2 3 4 5 6 7 8 9 A B C D E F
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120 180
60.0
<2>
60.0
<2>
E1-05
<1>
V 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0
60.0
<2>
60.0
<2>
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0
3.0
<2>
3.0
<2>
E1-08
<1>
V 14.0 14.0 14.0 14.0 35.0 50.0 35.0 50.0 18.0 23.0 18.0 23.0 14.0 14.0 14.0 14.0 11.0
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5
1.5
<2>
0.5
<2>
E1-10
<1>
V 7.0 7.0 7.0 7.0 6.0 7.0 6.0 7.0 9.0 11.0 9.0 13.0 7.0 7.0 7.0 7.0 2.0
<1> Values shown here are for 200 V class drives. Double the value when using a 400 V class drive.
<2>
The default value is for the following localized drives: Japan (Model code: CIMR-VAoA) and Asia (Model code: CIMR-VToA) .Refer to
China Localized Drive Default Values
on page 381 for the default values of China localized (Model code: CIMR-VBoA) drives.
