A.2 Single/Three-Phase 200 V Class Drive
Table A.2 Power Ratings
Item
Specification
Three-Phase Drive Model
2A0001 2A0002 2A0004 2A0006 2A0008 2A0010 2A0012 2A0018 2A0020
Single-Phase Drive Model
<1>
BA0001 BA0002 BA0003 BA0006 - BA0010 BA0012 -
BA0018
<2>
Maximum Motor Size Allowed (kW)
<3>
ND Rating
0.2 0.4 0.75 1.1 1.5 2.2 3.0 3.7
5.5
<2>
HD Rating
0.1 0.2 0.4 0.75 1.1 1.5 2.2 3.0 3.7
Input
Input
Current (A)
<4>
Three-
Phase
ND Rating
1.1 1.9 3.9 7.3 8.8 10.8 13.9 18.5 24.0
HD Rating
0.7 1.5 2.9 5.8 7.0 7.5 11.0 15.6 18.9
Single-
Phase
ND Rating
2.0 3.6 7.3 13.8 – 20.2 24.0 – –
HD Rating
1.4 2.8 5.5 11.0 – 14.1 20.6 – 35.0
Output
Rated Output Capacity
(kVA)
<5>
ND Rating
0.5 0.7 1.3 2.3 3.0 3.7 4.6 6.7 7.5
HD Rating
0.3 0.6 1.1 1.9 2.6 3.0 4.2 5.3 6.7
Output Current (A)
ND Rating
<6>
1.2 1.9
3.5
(3.3)
6.0 8.0 9.6 12.0 17.5 19.6
HD Rating
0.8
<7>
1.6
<7>
3.0
<7>
5.0
<7>
6.9
<8>
8.0
<8>
11.0
<8>
14.0
<8>
17.5
<8>
Overload Tolerance
ND Rating: 120% of rated output current for 1 minute
HD Rating: 150% of rated output current for 1 minute
(Derating may be required for applications that start and stop frequently)
Carrier Frequency
2 kHz (user-set, 2 to 15 kHz)
Max Output Voltage (V)
Three-phase power: 200 to 240 V
Single-phase power: 200 to 240 V
(both proportional to input voltage)
Max Output Frequency (Hz)
400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
DC power supply: 270 to 340 V
<9>
Allowable Voltage Fluctuation
-15 to 10%
Allowable Frequency Fluctuation
±5%
Harmonic Corrective
Actions
DC Reactor
Optional
<1> Drives with a single-phase power supply input output three-phase power, and cannot run a single-phase motor.
<2> This drive does not have a Normal Duty rating.
<3> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<4> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.
<5> Rated motor capacity is calculated with a rated output voltage of 220 V.
<6> Carrier frequency is set to 2 kHz (Swing PWM). Current derating is required to raise the carrier frequency.
<7> Carrier frequency is set to 10 kHz. Current derating is required to raise the carrier frequency.
<8> Carrier frequency is set to 8 kHz. Current derating is required to raise the carrier frequency.
<9>
DC is not available for UL standards.
A.2 Single/Three-Phase 200 V Class Drive
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
319
A
Specifications
