Table A.3 Power Ratings Continued
Item Specification
Three-Phase Drive Model 2A0030 2A0040 2A0056 2A0069
Single-Phase Drive Model
<1>
- - - -
Maximum Motor Size Allowed (kW)
<2>
ND Rating 7.5 11.0 15.0 18.5
HD Rating 5.5 7.5 11.0 15.0
Input
Input
Current (A)
<3>
Three-Phase
ND Rating 37.0 52.0 68.0 80.0
HD Rating 24.0 37.0 52.0 68.0
Single-Phase
ND Rating - - - -
HD Rating - - - -
Output
Rated Output Capacity
(kVA)
<4>
ND Rating 11.4 15.2 21.3 26.3
HD Rating 9.5 12.6 17.9 22.9
Output Current (A)
ND Rating
<5>
30.0 40.0 56.0 69.0
HD Rating
25.0
<7>
33.0
<7>
47.0
<7>
60.0
<7>
Overload Tolerance
ND Rating: 120% of rated output current for 1 minute
HD Rating: 150% of rated output current for 1 minute
(Derating may be required for applications that start and stop frequently)
Carrier Frequency 2 kHz (user-set, 2 to 15 kHz)
Max Output Voltage (V)
Three-phase power: 200 to 240 V
Single-phase power: 200 to 240 V
(both proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
DC power supply: 270 to 340 V
<6>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective
Actions
DC Reactor Optional
<1> Drives with single-phase power supply input will output three-phase power and cannot run a single-phase motor.
<2> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<3> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.
<4> Rated motor capacity is calculated with a rated output voltage of 220 V.
<5> Carrier frequency is set to 2 kHz (Swing PWM). Current derating is required to raise the carrier frequency.
<6> DC is not available for UL standards.
<7> Carrier frequency is set to 8 kHz. Current derating is required to raise the carrier frequency.
Note: Differences between Heavy Duty (HD) ratings and Normal Duty (ND) ratings for the drive include rated input and output current,
overload capacity, carrier frequency and current limit. Set parameter C6-01 to “0” for HD or “1” for ND (default).
A.2 Single/Three-Phase 200 V Class Drive
320
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
