YASKAWA V1000 Technical Manual

u
d: References
Reference parameters are used to set the various frequency reference values during operation.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01
<1>
Frequency Reference 1
Frequency reference. Refer to b1-01: Frequency Reference
Selection 1
on page 117 for instructions to use d1-01 as the
main frequency reference.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
S S S 280 154
d1-02
<1>
Frequency Reference 2
Frequency reference when digital input "Multi-Step Speed
Reference 1" (H1-oo = 3) is on.
0.00
Hz
S S S 281 154
d1-03
<1>
Frequency Reference 3
Frequency reference when digital input "Multi-Step Speed
Reference 2” (H1-oo = 4) is on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
S S S 282 154
d1-04
<1>
Frequency Reference 4
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2" (H1-oo = 3 and 4) are on.
0.00
Hz
S S S 283 154
d1-05
<1>
Frequency Reference 5
Frequency reference when digital input "Multi-Step Speed
Reference 3" (H1-oo = 5) is on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
A A A 284 154
d1-06
<1>
Frequency Reference 6
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 3 " (H1-oo = 3 and 5) are on.
0.00
Hz
A A A 285 154
d1-07
<1>
Frequency Reference 7
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 3" (H1-oo = 4 and 5) are on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
A A A 286 154
d1-08
<1>
Frequency Reference 8
Frequency reference when multi-function input "Multi-Step
speed reference 1, 2, 3" (H1-oo = 3, 4, 5) are on.
0.00
Hz
A A A 287 154
d1-09
<1>
Frequency Reference 9
Frequency reference when multi-function input "Multi-Step
Speed Reference 4" (H1-oo= 32) is on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
A A A 288 154
d1-10
<1>
Frequency Reference 10
Frequency reference when digital input "Multi-Step Speed
Reference 1, 4" (H1-oo = 3 and 32) are on.
0.00
Hz
A A A 28B 154
d1-11
<1>
Frequency Reference 11
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 4" (H1-oo = 4 and 32) are on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
A A A 28C 154
d1-12
<1>
Frequency Reference 12
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2, 4" (H1-oo = 3, 4, 32) are on.
0.00
Hz
A A A 28D 154
d1-13
<1>
Frequency Reference 13
Frequency reference when digital inputs "Multi-Step Speed
Reference 3, 4" (H1-oo = 5 and 32) are on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
A A A 28E 154
d1-14
<1>
Frequency Reference 14
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 3, 4" (H1-oo = 3, 5, 32) are on.
0.00
Hz
A A A 28F 154
d1-15
<1>
Frequency Reference 15
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 3, 4" (H1-oo = 4, 5, 32) are on.
0.00 to
400.00
Hz
<2> <3>
0.00
Hz
A A A 290 154
d1-16
<1>
Frequency Reference 16
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2, 3, 4" (H1-oo = 3, 4, 5, 32) are on.
0.00
Hz
A A A 291 154
d1-17
<1>
Jog Frequency Reference
Frequency reference when digital inputs "Jog Frequency
Reference", "Forward Jog", or "Reverse Jog." are on. "Jog
Frequency Reference" has priority over "Multi-Step Speed
Reference 1 to 16”.
0.00 to
400.00
Hz
<2> <3>
6.00
Hz
S S S 292 154
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01
Frequency Reference
Upper Limit
Sets the frequency reference upper limit as a percentage of
maximum output frequency (E1-04). Output speed is limited
to this value even if the frequency reference is higher. This
limit applies to all frequency reference sources.
0.0 to
110.0
100.0
%
A A A 289 155
d2-02
Frequency Reference
Lower Limit
Sets the frequency reference lower limit as a percentage of
maximum output frequency (E1-04). Output speed is limited
to
this value even if the frequency reference
is lower. This limit
applies to all frequency reference sources.
0.0 to
110.0
0.0% A A A 28A 155
d2-03
Master Speed Reference
Lower Limit
Sets the minimum frequency reference lower limit if the
frequency reference is input using an analog input. Set as a
percentage of maximum output frequency (E1-04). The higher
of both values d2-02 and d2-03 will be the lower limit.
0.0 to
110.0
0.0% A A A 293 155
d3: Jump Frequency
Use d3 parameters to configure the drive Jump Frequency settings.
B.2 Parameter Table
340
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
