YASKAWA V1000 - Pulse Train Input;Analog Inputs (AC Common); Multi-Function Digital Outputs (MC Common); Multi-Function Photocoupler Outputs (PC Common); Monitor Outputs (AC Common)

Terminal
Used/
Reserved
Setting Value and Function Name Memo
S7 H1-07 =
u
Pulse Train Input/Analog Inputs (AC Common)
Terminal
Used/
Reserved
Setting Value and Function Name Memo
RP H6-01 =
A1 H3-02 =
A2 H3-10 =
u
Multi-Function Digital Outputs (MC Common)
Terminal
Used/
Reserved
Setting Value and Function Name Memo
MA-MB H2-01 =
u
Multi-Function Photocoupler Outputs (PC Common)
Terminal
Used/
Reserved
Setting Value and Function Name Memo
P1 H2-02 =
P2 H2-03 =
u
Monitor Outputs (AC Common)
Terminal
Used/
Reserved
Setting Value and Function Name Memo
MP
AM H4-01 =
