No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
A1-07
<2>
DriveWorksEZ
Function Selection
0: Disabled
1: Enabled
2: Multi-function input (enabled when H1-oo = 9F)
0 to 2 0 A A A 128 115
A2: User Parameters
Use A2 parameters to program the drive.
A2-01
to
A2-32
User Parameters, 1 to
32
Parameters that were recently edited are listed here. The user can
also select parameters to appear here for quick
access. Parameters
will be stored here for quick access when A1-01 = 1.
A1-00 to
o2-08
<3>
A A A
106 to
125
115
A2-33
User Parameter
Automatic Selection
0: Parameters A2-01 through A2-32 are reserved for the user to
create a list of User Parameters.
1: Save history of recently viewed parameters. Recently edited
parameters will be saved to A2-17 through A2-32 for quick access.
0, 1
<5>
A A A 126 116
<1> Parameter can be changed during run.
<2> Parameter setting value is not reset to the default value during drive initialization, A1-03 = 1110, 2220, 3330.
<3> Default setting value is dependent on parameter A1-06, Application Selection.
<4> Available in drive software versions PRG: 1020 and later.
<5>
Default setting value is dependent on parameter A1-06. This setting value is 0 when A1-06 = 0, and 1 when A1-06 ≠ 0.
<6> Regional default settings:
Setting 0: Japan (Model code: CIMR-VAoA) and Asia (Model code: CIMR-VToA)
Setting 7: China (Model code: CIMR-VBoA)
u
b: Application
Application parameters configure the Run Command Source, DC
Injection Braking, Speed Search, Timer functions, PID
control, the Dwell function, Energy Savings and a variety of other application-related settings.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
b1: Operation Mode Selection
Use b1 parameters to configure the operation mode.
b1-01
Frequency Reference
Selection 1
Selects the frequency reference input source.
0: Digital operator - Digital preset speed d1-01 to d1-17.
1: Terminals - Analog input terminal A1 or A2.
2: MEMOBUS communications
3: Option PCB
4: Pulse Input (Terminal RP)
0 to 4 1 S S S 180 117
b1-02 Run Command Selection 1
Selects the run command input source.
0: Digital operator - RUN and STOP keys on the digital
operator.
1: Digital input terminals
2: MEMOBUS communications
3: Option PCB.
0 to 3 1 S S S 181 119
b1-03 Stopping Method Selection
Selects the stopping method when the run command is
removed.
0: Ramp to Stop
1: Coast to Stop
2: DC Injection Braking to Stop
3: Coast with Timer
(A
new run command is ignored if received
before the timer
expires)
0 to 3 0 S S S 182 120
DC Injection Braking at Stop cannot be
selected when using Open Loop Vector for
PM motors.
b1-04
Reverse Operation
Selection
Permits or prohibits reverse operation.
0: Reverse enabled.
1: Reverse disabled.
0, 1 0 A A A 183 122
b1-07
LOCAL/REMOTE Run
Selection
Determines the operation when the Run command source is
switched from LOCAL to REMOTE or between Run source
1 and 2 while an external Run command is active at the new
source.
0: External Run command has to be cycled at the new source
to be activated.
1: External Run command at new source is accepted
immediately.
0, 1 0 A A A 186 122
B.2 Parameter Table
332
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
