YASKAWA V1000 Technical Manual

A.3 Three-Phase 400 V Class Drives
Table A.4 Power Ratings
Item Specification
Three-Phase Drive Model
4A0001 4A0002 4A0004 4A0005 4A0007 4A0009 4A0011
Maximum Applicable Motor Capacity
(kW)
<1>
ND Rating 0.37 0.75 1.5 2.2 3.0 4.0 5.5
HD Rating 0.37 0.55 1.1 1.5 2.2 3.0 3.7
Input
Input Current (A)
<2>
ND Rating 1.2 2.1 4.3 5.9 8.1 9.4 14.0
HD Rating 1.2 1.8 3.2 4.4 6.0 8.2 10.4
Output
Output Current (kVA)
<3>
ND Rating
<4>
0.9 1.6 3.1 4.1 5.3 6.7 8.5
HD Rating
<5>
0.9 1.4 2.6 3.7 4.2 5.5 7.0
Output Current (A)
ND Rating
<4>
1.2 2.1 4.1 5.4 6.9 8.8 11.1
HD Rating
<5>
1.2 1.8 3.4 4.8 5.5 7.2 9.2
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
HD Rating: 150% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency 2 kHz (user-adjustable from 2 to 15 kHz)
Maximum Output Voltage (V) Three-phase power: 380 to 480 V (proportional to input voltage)
Maximum Output Frequency (Hz) 400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: 380 to 480 V 50/60 Hz
DC power supply: 510 to 680 V
<6>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective Actions DC Reactor Optional
<1> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<2> Input current rating varies depending on the power supply transformer, input reactor, wiring conditions, and power supply impedance.
<3> Rated motor capacity is calculated with a rated output voltage of 440 V.
<4> Carrier frequency is set to 2 kHz (Swing PWM). Current derating is required in order to raise the carrier frequency.
<5> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
<6> DC is not available for UL standards.
A.3 Three-Phase 400 V Class Drives
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
321
A
Specifications

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
