YASKAWA V1000 Technical Manual

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
o4-12 kWh Monitor Initialization
0: U4-10 and U4-11 monitor data are not reset when the drive
is initialized using A1-03.
1:
U4-10 and U4-11 monitor data are reset when the drive is
initialized using A1-03. (The value of o4-12 is automatically
returned to 0.)
0, 1 0 A A A 512 240
o4-13
Number of Run Commands
Initialize Selection
0: U4-02 monitor data is not reset when the drive is
initialized using A1-03.
1: U4-02 monitor data is reset when the drive is initialized
using A1-03. (The value of o4-13 is automatically returned
to 0.)
0, 1 0 A A A 528 240
<1> Parameter can be changed during run.
<2> Setting range is determined by drive software version.
PRG: 1016 and later: 104 to 810
PRG: 1015 and earlier: 104 to 621
<3> Default setting value is dependent on parameter o1-03, Digital Operator Display Selection.
<4> Parameter setting value is not reset to the default value during drive initialization, A1-03 = 1110, 2220, 3330
<5> Default setting value is dependent on parameter o2-04, Drive Model Selection.
<6> Available in drive software versions PRG: 1011 and later. Parameter o4-03 is set in 10 h units. When o4-03 = 30, the operation time for the
cooling fan will start counting from 300 hours, and monitor U4-03 will display “300 H”. Earlier software versions set o4-03 in 1 h units.
<7> Available in drive software versions PRG: 1022 and later.
u
q: DriveWorksEZ Parameters
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
q1-01 to
q6-07
DriveWorksEZ
Parameters
Reserved for DriveWorksEZ. - - A A Α - —
u
r: DriveWorksEZ Connection Parameters
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
r1-01
DriveWorksEZ Connection
Parameter 1 (upper)
Parameter 1 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1840 —
r1-02
DriveWorksEZ Connection
Parameter 1 (lower)
Parameter 1 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1841 —
r1-03
DriveWorksEZ Connection
Parameter 2 (upper)
Parameter 2 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1842 —
r1-04
DriveWorksEZ Connection
Parameter 2 (lower)
Parameter 1 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1843 —
r1-05
DriveWorksEZ Connection
Parameter 3 (upper)
Parameter 1 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1844 —
r1-06
DriveWorksEZ Connection
Parameter 3 (lower)
Parameter 3 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1845 —
r1-07
DriveWorksEZ Connection
Parameter 4 (upper)
Parameter 4 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1846 —
r1-08
DriveWorksEZ Connection
Parameter 4 (lower)
Parameter 4 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1847 —
r1-09
DriveWorksEZ Connection
Parameter 5 (upper)
Parameter 5 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1848 —
r1-10
DriveWorksEZ Connection
Parameter 5 (lower)
Parameter 5 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1849 —
r1-11
DriveWorksEZ Connection
Parameter 6 (upper)
Parameter 6 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 184A —
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
369
B
Parameter List

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
