1.3 Drive Models and Enclosure Types
The following table describes drive enclosures and models.
Table 1.1 Drive Models and Enclosure Types
Voltage Class
Enclosure Type
IP20/Open-Chassis
Drive Model
IP00/Open-Chassis
Drive Model
IP20/NEMA Type 1
Drive Model
Single-Phase
200 V Class
BA0001B –
<1>
BA0002B –
BA0003B –
BA0006B –
BA0010B –
BA0012B –
BA0018B –
Three-Phase
200 V Class
2A0001B –
2A0002B –
2A0004B –
2A0006B –
2A0008B –
2A0010B –
2A0012B –
2A0018B –
2A0020B –
–
<2>
2A0030F
– 2A0040F
– 2A0056F
– 2A0069F
Three-Phase
400 V Class
4A0001B –
<1>
4A0002B –
4A0004B –
4A0005B –
4A0007B –
4A0009B –
4A0011B –
–
<2>
4A0018F
– 4A0023F
– 4A0031F
– 4A0038F
<1> Models in this capacity range have IP20/Open-Chassis enclosures. Customers may convert these models to IP20/NEMA Type 1 enclosures
using an IP20/NEMA Type 1 Kit (EZZ020564o).
<2> Models in this capacity range have IP20/NEMA Type
1 enclosures. Customers may convert these models to IP00/Open-Chassis enclosures by
removing the top and bottom covers. Refer to IP00/Open-Chassis on page 32 for details.
Two types of enclosures are offered for V1000 drives.
• IP20/Open-Chassis and IP00/Open-Chassis models are often placed inside a large enclosure panel where the front of
the drive is covered to prevent someone from accidentally touching charged components.
• IP20/NEMA Type 1 models mount to an indoor wall and not inside a large enclosure panel.
Note: Drive models and protective enclosures referenced by footnotes 1 and 2 should specify the enclosure method using parameter L8-35.
Refer to Temperature Derating on page 327 for more information.
1.3 Drive Models and Enclosure Types
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
29
