A.5 Drive Watt Loss Data
Table A.6 Watt Loss 200 V Class Single-Phase Models
Drive Model
Heavy Duty (Carrier Frequency 8 kHz)
<1>
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
BA0001 0.8 4.3 7.4 11.7 1.2 5.0 8.5 13.5
BA0002 1.6 7.9 8.9 16.7 1.9 7.6 9.7 17.3
BA0003 3.0 16.1 11.5 27.7 3.2 14.6 14.4 29.1
BA0006 5.0 33.7 16.8 50.5 6.0 30.1 19.4 49.5
BA0010 8.0 54.8 25.9 80.7 9.6 51.7 29.8 81.4
BA0012 11.0 70.7 34.1 104.8 12.0 61.3 37.1 98.4
BA0018 17.5 110.5 51.4 161.9 — — — —
<1> 10 kHz for BA0001 to BA0006
Table A.7 Watt Loss 200 V Class Three-Phase Models
Drive Model
Heavy Duty (Carrier Frequency 8 kHz)
<1>
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
2A0001 0.8 4.3 7.3 11.6 1.2 5.0 8.0 13.0
2A0002 1.6 7.9 8.8 16.7 1.9 7.6 9.5 17.1
2A0004 3.0 16.2 11.5 27.7 3.5 15.8 13.6 29.4
2A0006 5.0 27.4 15.9 43.3 6.0 27.5 17.2 44.7
2A0008 7.0 48.7 22.2 70.9 8.0 44.6 24.0 68.6
2A0010 8.0 54.8 23.8 78.6 9.6 51.7 25.8 77.5
2A0012 11.0 70.7 29.9 100.6 12.0 61.3 30.4 91.7
2A0018 14.0 92.6 38.8 131.4 18.0 89.8 44.1 133.8
2A0020 17.5 110.5 43.3 153.8 19.6 98.7 46.3 145.0
2A0030 25.0 231.5 72.2 303.7 30.0 246.4 88.9 335.3
2A0040 33.0 339.5 82.8 321.3 40.0 266.7 112.8 379.6
2A0056 47.0 347.6 117.6 465.2 56.0 357.9 151.8 509.7
2A0069 60.0 437.7 151.4 589.1 69.0 461.7 184.5 646.2
<1> 10 kHz for 2A0001 to 2A0006
Table A.8 Watt Loss 400 V Class Three-Phase Models
Drive Model
Heavy Duty (Carrier Frequency 8 kHz) Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
4A0001 1.2 19.2 11.5 30.7 1.2 10.0 9.6 19.6
4A0002 1.8 28.9 14.8 43.7 2.1 18.5 13.9 32.4
4A0004 3.4 42.3 17.9 60.2 4.1 30.5 16.8 47.3
4A0005 4.8 70.7 26.2 96.9 5.4 44.5 21.8 66.3
4A0007 5.5 81.0 30.7 111.7 6.9 58.5 28.4 86.9
4A0009 7.2 84.6 32.9 117.5 8.8 63.7 31.4 95.1
4A0011 9.2 107.2 41.5 148.7 11.1 81.7 46.0 127.7
4A0018 14.8 166.0 62.7 228.7 17.5 181.2 80.1 261.3
4A0023 18.0 207.1 78.1 285.2 23.0 213.4 107.7 321.1
4A0031 24.0 266.9 105.9 372.8 31.0 287.5 146.1 433.6
4A0038 31.0 319.1 126.6 445.7 38.0 319.2 155.8 475.0
A.5 Drive Watt Loss Data
