Table D.3 Three-Phase 200 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Manufacturer: Fuji Electric
Type
Rated Short Circuit
Braking Current
(kA)
Qty. Type Qty.
2A0001 CR6L-20/UL
100 2
CMS-4
2
2A0002 CR6L-20/UL CMS-4
2A0004 CR6L-20/UL CMS-4
2A0006 CR6L-30/UL CMS-4
2A0008 CR6L-50/UL CMS-4
2A0010 CR6L-50/UL CMS-4
2A0012 CR6L-50/UL CMS-4
2A0018 CR6L-75/UL CMS–5
2A0020 CR6L-75/UL CMS–5
2A0030 CR6L-100/UL CMS–5
2A0040 CR6L-150/UL CMS–5
2A0056 CR6L-150/UL CMS–5
2A0069 CR6L-200/UL
<1>
–
<1> Manufacturer does not recommend a specific fuse holder
for this fuse. Contact Yaskawa or your nearest sales representative for fuse dimensions.
Table D.4 Three-Phase 400 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Manufacturer: Fuji Electric
Type
Rated Short Circuit
Braking Current
(kA)
Qty. Type Qty.
4A0001 CR6L-20/UL
100 2
CMS-4
2
4A0002 CR6L-20/UL CMS-4
4A0004 CR6L-50/UL CMS-4
4A0005 CR6L-50/UL CMS-4
4A0007 CR6L-50/UL CMS-4
4A0009 CR6L-50/UL CMS-4
4A0011 CR6L-50/UL CMS-4
4A0018 CR6L-50/UL CMS-4
4A0023 CR6L-75/UL CMS–5
4A0031 CR6L-100/UL CMS–5
4A0038 CR6L-150/UL CMS–5
n
Guarding Against Harmful Materials
When installing IP20/Open-Chassis enclosure drives, use an enclosure that prevents foreign material from entering the
drive from above or below.
u
EMC Guidelines Compliance
This drive is tested according to European standards IEC/EN 61800-3 and it complies with the EMC guidelines.
n
EMC Filter Installation
The following conditions must be met to ensure continued compliance with guidelines. Refer to EMC Filters on page
439 for EMC filter selection.
Installation Method
Verify
the following installation conditions to ensure that
other devices and machinery used in combination with this drive
also comply with EMC guidelines.
1.
Install an EMC noise filter to the input side specified by Yaskawa for compliance with European standards.
2.
Place the drive and EMC noise filter in the same enclosure.
3.
Use braided shield cable for the drive and motor wiring or run the wiring through a metal conduit.
D.2 European Standards
436
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
