YASKAWA V1000 Technical Manual

u
SS5 Motor: Yaskawa SSR1 Series IPM Motor
Default values vary based on drive software version.
n
Drive Software Version PRG: 1017 and Earlier
Table B.11 200 V, 1750 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1202 1203 1205 1206 1208 120A 120B 120D 120E 120F
Voltage Class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.0
E5-03 Motor Rated Current A 1.65 2.97 5.50 8.10 13.40 19.80 27.00 39.7 53.2 65.5
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05 Motor Winding Resistance Ω 8.233 2.284 1.501 0.827 0.455 0.246 0.198 0.094 0.066 0.052
E5-06 d-Axis Inductance mH 54.84 23.02 17.08 8.61 7.20 4.86 4.15 3.40 2.65 2.17
E5-07 q-Axis Inductance mH 64.10 29.89 21.39 13.50 10.02 7.43 5.91 3.91 3.11 2.55
E5-09
Induction Voltage
Constant 1
mVs/rad 233.0 229.5 250.9 247.9 248.6 249.6 269.0 249.3 266.6 265.1
E5-24
Induction Voltage
Constant 2
mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04
Maximum Output
Frequency
Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Output Voltage V 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09
Minimum Output
Frequency
Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
<1>
Motor Acceleration Time
for Inertia Calculations
s 0.092 0.076 0.051 0.066 0.075 0.083 0.077 0.084 0.102 0.103
n8-49
d-Axis Current for High-
Efficiency Control
% –7.2 –10.8 –11.1 –17.8 –17.5 –22.0 –17.3 –10.1 –10.3 –10.1
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
391
B
Parameter List

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
