Drive Software Version PRG: 1018 and Later
Table B.12 200 V, 1750 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1202 1203 1205 1206 1208 120A 120B 120D 120E 120F
Voltage Class − 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac 200 Vac
Rated Power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW 5.5 kW 7.5 kW 11 kW 15 kW 18 kW
Rated Speed r/min 1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5
E5-03 Motor Rated Current A 1.77 3.13 5.73 8.44 13.96 20.63 28.13 41.4 55.4 68.2
E5-04 Motor Pole Number – 6 6 6 6 6 6 6 6 6 6
E5-05 Motor Winding Resistance Ω 8.233 2.284 1.470 0.827 0.455 0.246 0.198 0.094 0.066 0.051
E5-06 d-Axis Inductance mH 54.84 23.02 17.22 8.61 7.2 4.86 4.15 3.4 2.45 2.18
E5-07 q-Axis Inductance mH 64.1 29.89 20.41 13.5 10.02 7.43 5.91 3.91 3.11 2.55
E5-09
Induction Voltage
Constant 1
mVs/rad 223.7 220.3 240.8 238 238.7 239.6 258.2 239.3 248.1 253.6
E5-24
Induction Voltage
Constant 2
mV/(r/min) 0 0 0 0 0 0 0 0 0 0
E1-04
Maximum Output
Frequency
Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Output Voltage V 190 190 190 190 190 190 190 190 190 190
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09
Minimum Output
Frequency
Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
<1>
Motor Acceleration Time
for Inertia Calculations
s 0.092 0.076 0.051 0.066 0.075 0.083 0.077 0.084 0.102 0.101
n8-49
d-Axis Current for High-
Efficiency Control
% –7.6 –11.5 –9.1 –19 –18.7 –23.4 –18.5 –10.9 –16.5 –11.3
<1> Default setting value is dependent on parameter o2-04, Drive Model Selection.
B.7 Parameters that Change with the Motor Code Selection
392
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
