YASKAWA V1000 Technical Manual

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
r1-12
DriveWorksEZ Connection
Parameter 6 (lower)
Parameter 6 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 184BH —
r1-13
DriveWorksEZ Connection
Parameter 7 (upper)
Parameter 7 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 184C —
r1-14
DriveWorksEZ Connection
Parameter 7 (lower)
Parameter 7 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 184D —
r1-15
DriveWorksEZ Connection
Parameter 8 (upper)
Parameter 8 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 184E —
r1-16
DriveWorksEZ Connection
Parameter 8 (lower)
Parameter 8 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 184F —
r1-17
DriveWorksEZ Connection
Parameter 9 (upper)
Parameter 9 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1850 —
r1-18
DriveWorksEZ Connection
Parameter 9 (lower)
Parameter 9 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1851 —
r1-19
DriveWorksEZ Connection
Parameter 10 (upper)
Parameter 10 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1852 —
r1-20
DriveWorksEZ Connection
Parameter 10 (lower)
Parameter 10 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1853 —
r1-21
DriveWorksEZ Connection
Parameter 11 (upper)
Parameter 11 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1854 —
r1-22
DriveWorksEZ Connection
Parameter 11 (lower)
Parameter 11 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1855 —
r1-23
DriveWorksEZ Connection
Parameter 12 (upper)
Parameter 12 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1856 —
r1-24
DriveWorksEZ Connection
Parameter 12 (lower)
Parameter 12 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1857 —
r1-25
DriveWorksEZ Connection
Parameter 13 (upper)
Parameter 13 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1858 —
r1-26
DriveWorksEZ Connection
Parameter 13 (lower)
Parameter 13 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1859 —
r1-27
DriveWorksEZ Connection
Parameter 14 (upper)
Parameter 14 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 185A —
r1-28
DriveWorksEZ Connection
Parameter 14 (lower)
Parameter 14 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 185B —
r1-29
DriveWorksEZ Connection
Parameter 15 (upper)
Parameter 15 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 185C —
r1-30
DriveWorksEZ Connection
Parameter 15 (lower)
Parameter 15 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 185D —
r1-31
DriveWorksEZ Connection
Parameter 16 (upper)
Parameter 16 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 185E —
r1-32
DriveWorksEZ Connection
Parameter 16 (lower)
Parameter 16 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 185F —
r1-33
DriveWorksEZ Connection
Parameter 17 (upper)
Parameter 17 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1860 —
r1-34
DriveWorksEZ Connection
Parameter 17 (lower)
Parameter 17 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1861 —
r1-35
DriveWorksEZ Connection
Parameter 18 (upper)
Parameter 18 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1862 —
r1-36
DriveWorksEZ Connection
Parameter 18 (lower)
Parameter 18 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1863 —
r1-37
DriveWorksEZ Connection
Parameter 19 (upper)
Parameter 19 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1864 —
r1-38
DriveWorksEZ Connection
Parameter 19 (lower)
Parameter 19 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1865 —
r1-39
DriveWorksEZ Connection
Parameter 20 (upper)
Parameter 20 for connecting DriveWorksEZ (upper).
0 to
FFFFH
0 – A A 1866 —
r1-40
DriveWorksEZ Connection
Parameter 20 (lower)
Parameter 20 for connecting DriveWorksEZ (lower).
0 to
FFFFH
0 – A A 1867 —
u
T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance
B.2 Parameter Table
370
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
