No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
C3-02
Slip Compensation Primary
Delay Time
Adjusts the slip compensation function delay time.
Decrease
the setting when the slip compensation response
is too slow, increase it when the speed is not stable.
Disabled when Simple V/f Control with PG (H6-01 = 3)
is used.
0 to 10000
2000
ms
<4>
A A − 210 146
C3-03 Slip Compensation Limit
Sets the slip compensation upper limit. Set as a percentage
of motor rated slip (E2-02). Disabled when Simple V/f
Control with PG (H6-01 = 3) is used.
0 to 250 200% A A − 211 146
C3-04
Slip Compensation
Selection during
Regeneration
Selects slip compensation during regenerative operation.
0: Disabled
1: Enabled
Using the Slip Compensation function during
regeneration may require a braking option to handle
momentary increasing regenerative energy.
0, 1 0 A A − 212 146
C3-05
Output Voltage Limit
Operation Selection
Selects if the motor magnetic flux is reduced during output
voltage saturation.
0: Disabled
1: Enabled
0, 1
0
<4>
− A − 213 147
C4: Torque Compensation
Use C4 parameters to configure Torque Compensation function.
C4-01
<5>
Torque Compensation
Gain
V/f Control: Sets the gain for the automatic torque
(voltage) boost function and helps to produce better
starting torque.
Increase this setting when using a long motor cable or
when the motor is significantly smaller than the drive
capacity.
Decrease this setting when motor oscillation occurs. Set
the
value so that the current at low speed does not exceeds
the drives rated current.
Open Loop Vector: Sets the torque compensation function
gain. Normally no change is required.
0.00 to 2.50
1.00
<4>
A A A 215 147
C4-02
Torque Compensation
Primary Delay Time
Sets the torque compensation filter time.
Increase this setting when motor oscillation occurs.
Reduce the setting if there is not enough response from
the motor.
0 to 60000
200
ms
<6>
A A A 216 147
C4-03
Torque Compensation at
Forward Start
Sets torque compensation at forward start as a percentage
of motor torque.
0.0 to 200.0 0.0% − A − 217 147
C4-04
Torque Compensation at
Reverse Start
Sets torque compensation at reverse start as a percentage
of motor torque.
-200.0 to
0.0
0.0% − A − 218 148
C4-05
Torque Compensation Time
Constant
Sets the time constant for torque compensation at forward
start and reverse start (C4-03 and C4-04). The filter is
disabled if the time is set to 4 ms or less.
0 to 200 10 ms – A – 219 148
C4-06
Torque Compensation
Primary Delay Time 2
Sets the torque compensation time 2. When an ov fault
occurs with sudden load changes or at the and of an
acceleration, increase the setting.
Note: Adjustment is not normally required. If adjusted
then AFR time 2 (n2-03) should be adjusted too.
0 to 10000
150
ms
– A – 21AH 148
C5: Speed Control (ASR)
Use C5 parameters to configure the Automatic Speed Regulator (ASR).
C5 parameters are available only when using V/f Control with Simple PG Feedback (H6-01 = 3).
C5-01
<1>
ASR Proportional Gain 1
Sets the proportional gain of the speed control loop
(ASR).
0.00 to
300.00
0.20 A
– –
21B 149
C5-02
<1>
ASR Integral Time 1 Sets the integral time of the speed control loop (ASR).
0.000 to
10.000
0.200 A 21C 149
C5-03
<1>
ASR Proportional Gain 2
Sets the speed control gain 2 of the speed control loop
(ASR).
0.00 to
300.00
0.02 A − − 21D 149
C5-04
<1>
ASR Integral Time 2 Sets the integral time 2 of the speed control loop (ASR).
0.000 to
10.000
0.050 s A
– –
21E 149
C5-05
<1>
ASR Limit
Sets the upper limit for the speed control loop (ASR) as a
percentage of the maximum output frequency (E1-04).
0.0 to 20.0 5.0% A 21F 150
C6: Carrier Frequency
Use C6 parameters to configure the carrier frequency drive settings.
B.2 Parameter Table
338
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
