No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
H3-13
Analog Input Filter Time
Constant
Sets the primary delay filter time constant for terminals A1
and A2. Used for noise filtering.
0.00 to
2.00
0.03 s A A A 41B 198
H3-14
<3>
Analog Input Terminal
Enable Selection
Determines which analog input terminal will be enabled
when a digital input programmed for “Analog input enable”
(H1-oo = C) is activated.
1: Terminal A1 only
2: Terminal A2 only
7: All terminals enabled
1, 2, 7 7 A A A 41C 200
H3-16
<3>
Terminal A1 Offset
Enter a 0 V signal to terminal A1. Next adjust the offset in
H3-16 until the monitor U1-13 for the terminal A1 input
voltage reads 0.0%. The process is the same for terminal
A2.
-500 to 500 0 A A A 440 200
H3-17
<3>
Terminal A2 offset
Enter a 0 V signal, and adjust the offset for terminal A2 in
H3-17 until the monitor U1-14 for terminal A2 input
voltage reads 0.0%.
-500 to 500 0 A A A 441 200
<1> The availability of certain parameters depends on the control method used.
<2> Parameter can be changed during Run.
<3> Parameter available in drive software versions PRG: 1016 and later.
H3 Multi-Function Analog Input Settings
H3-oo
Setting
Function Maximum Input Level Possible
Control
Mode
Pg.
V/
f
O
L
V
P
M
0 Frequency Bias
Max output frequency (E1-04).
Same value can be set using H3-02 and H3-10.
O O O 198
1 Frequency Gain 10 V = 100% O O O 199
2
Auxiliary Frequency Reference (used as a
Multi-Step Speed 2)
Maximum output frequency (E1-04) O O O 199
4 Output Voltage Bias Motor rated voltage (E1-05). O – − 199
7 Overtorque/Undertorque Detection Level
Open Loop Vector: Motor rated torque
V/f Control: Drive rated current
O O O 199
B PID Feedback 10 V = 100% O O O 199
C PID Set Point 10 V = 100% O O O 199
E Motor Temperature (PTC input) 10 V = 100.00% O O O 199
F Not used/Through Mode – O O O 199
10 FWD Torque Limit Motor rated torque − O − 199
11 REV Torque Limit Motor rated torque − O − 199
12 Regenerative Torque Limit Motor rated torque − O − 199
15 FWD/REV Torque Limit Motor rated torque − O − 199
16 Differential PID Feedback 10 V = 100% O O O 199
30/31 DWEZ Analog Input 1/2 Depending on function. O O O 200
41
<1>
Output Voltage Gain 10 V = 100% O − − 199
<1> Parameter available in drive software versions PRG: 1016 and later.
No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/
f
O
L
V
P
M
H4: Multi-Function Analog Outputs
Use H4 parameters to configure the multi-function analog output terminals.
H4-01
Multi-Function Analog
Output Terminal AM
Selects the data to be output through multi-function analog
output terminal AM.
Set the desired monitor parameter to the digits available in
Uo-oo. For example, enter “103” for U1-03.
When
using this terminal in through mode or
when not using
it at all, set “000” or “031”.
000 to
999
<1>
102 A A A 41D 200
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual
355
B
Parameter List
