No. Name Setting Range Default
H6-02 Pulse Train Input Scaling
<1>
1440 Hz
<1> Setting range is determined by drive software version.
PRG: 1016 and later: 100 to 32000 Hz
PRG: 1015 and earlier: 1000 to 32000 Hz
n
H6-03: Pulse Train Input Terminal RP Gain
Sets
the level of the value selected in
H6-01 when a pulse train signal with the frequency set in H6-02 is input to terminal
RP.
No. Name Setting Range Default
H6-03 Pulse Train Input Gain 0.0 to 1000.0% 100.0%
n
H6-04: Pulse Train Input Terminal RP Bias
Sets the level of the value selected in H6-01 when a 0 Hz signal is input to terminal RP.
No. Name Setting Range Default
H6-04 Pulse Train Input Bias -100.0 to 100.0% 0.0%
n
H6-05: Pulse Train Input Terminal RP Filter Time
Sets the pulse train input filter time constant in seconds.
The pulse train input filter helps prevent noise interference from causing erroneous operation when operating the drive
within the pulse train signal.
Increasing
the
filter
setting
time
increases
the
effectiveness
of the noise prevention, however, this also increasingly slows
drive response time.
No. Name Setting Range Default
H6-05 Pulse Train Input Filter Time 0.00 to 2.00 s 0.10 s
n
H6-06: Pulse Train Output Terminal MP Monitor Selection
Selects
the
pulse
train
monitor
output
terminal
MP
function. The set value ooo is equal to the numerals in Uo-oo of
the selected monitor. Refer to U: Monitors on page 371 for a complete list of monitors. Selectable monitor items are
listed below.
No. Name Setting Range Default
H6-06 Pulse Train Output Terminal MP Monitor Selection
000, 031, 101, 102, 105,
116, 501, 502, 801 to 809
102
n
H6-07: Pulse Train Output Terminal MP Monitor Scaling
Pulse train monitor scaling sets the output frequency at terminal MP when the monitor item is 100%. Set H6-06 to 102
and H6-07 to 0 to make the pulse train monitor output synchronous to the output frequency.
No. Name Setting Range Default
H6-07 Pulse Train Input Monitor Scaling 0 to 32000 Hz 1440 Hz
5.7 H: Terminal Functions
