YASKAWA V1000 Technical Manual

Revision History
The revision dates and the numbers of the revised manuals appear on the bottom of the back cover.
Date of Publication
Revision
Number
Section Revised Content
March 2014
2
All
Revision: Reviewed and corrected documentation
Revision: Upgraded the software versions from PRG:
1021 to PRG:
1023
Chapter 2 Revision: Ambient Temperature
Chapter 3 Revision: Wire Gauge and Torque Specifications
Appendix A
Revision: Ambient Temperature
Revision: Standards
Appendix D
Addition: Fuse List for European Standards
Addition: Ambient Temperature for UL Standards
Revision: Wire Gauge and Torque Specifications for UL Standards
Revision: Standards
Revision: Low Voltage Wiring for Control Circuit Terminals
Back Cover Revision: Address
December 2011
1
Cover Revision: Format
All
Revision: Reviewed and corrected documentation
Upgraded the software versions from PRG: 1011 to PRG: 1021
Chapter 3
Revision: Wire Gauge and Torque Specifications
Revision: Precautions on installing a leakage breaker
Chapter 8 Revision: Precautions on installing a leakage breaker
Appendix D
Revision: Wire Gauge and Torque Specifications
Revision: Closed-Loop Crimp Terminal Size
Revision: Fuse List
Addition: Precautions for Korean Radio Waves Act
Back Cover Revision: Format and address
June 2008 - - First Edition
478
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
