Table 3.16 Braking Resistor Settings
Parameter Settings
L8-01:
Internal Dynamic Braking Resistor Protection Selection
0: Disabled. The drive will not provide overheat protection.
Supply separate means of overheat protection.
1: Enabled. Braking Resistor is protected from overheat.
L3-04
: Stall Prevention During Deceleration
Note: Select either 0 or 3
0: Stall prevention disabled.
3: Stall prevention enabled with a braking resistor
Note: This
setting
cannot
be
used
in
OLV control for PM
motor.
8.
Operate the system and verify the required deceleration rate is obtained during dynamic braking or stopping.
3.11 Braking Resistor
72
YASKAWA ELECTRIC SIEP C710606 16C YASKAWA AC Drive – V1000 Technical Manual

YASKAWA V1000 Specifications

General

Input Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Voltage	3-Phase 200-240VAC, 3-Phase 380-480VAC
Output Frequency	0-400 Hz
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit, Ground Fault
Communication Options	Modbus RTU
Ambient Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20°C to +65°C (-4°F to 149°F)
Humidity	95% (non-condensing)
Cooling Method	Forced Air Cooling
Enclosure	IP20
