YOKOGAWA ADMAG TI Series User Manual

<5. Functions>
106
IM 01E21A02-03EN
From the table below, select the alarm display.
Selection
Description
Display
F
OUNDATION
Fieldbus
Normal Normal Sets to the normal alarm display.
NE107 NE107 Sets the alarm display based on NAMUR NE107.
5.6.5 Alarm Record Function
The alarm record function can record an alarm that occurred in the past as history.
Thesettingcanbeconguredwiththefollowingparameters.
Menu path
Display Devicesetup►Diag/Service►Sts/Selftest►Alarm►Alarmrecord►(seebelow)
F
OUNDATION
Fieldbus
Diagnostic►STB►DeviceDiagnostics►Diagnostics/Alerts►Alert►AlarmRecord►
(seebelow)
Block
Name
Relative
Index
Parameter
Description
Display F
OUNDATION Fieldbus
STB 155 Record alarm 1 Alarm Record 1
Displaysthenameoftherst
new alarm.
STB 156 Record time 1 Alarm Time 1
Displays the operation time
whentherstnewalarm
occurs.
STB 157 Record alarm 2 Alarm Record 2
Displays the name of the
second new alarm.
STB 158 Record time 2 Alarm Time 2
Displays the operation time
when the second new alarm
occurs.
STB 159 Record alarm 3 Alarm Record 3
Displays the name of the third
new alarm.
STB 160 Record time 3 Alarm Time 3
Displays the operation time
when the third new alarm
occurs.
STB 161 Record alarm 4 Alarm Record 4
Displays the name of the fourth
new alarm.
STB 162 Record time 4 Alarm Time 4
Displays the operation time
when the fourth new alarm
occurs.
Theoperationtimewhenanalarmoccurredisdisplayedintheformatof“dddddDhh:mm”.
“dddddD”indicatestheday,“hh”indicatesthehour,and“mm”indicatestheminute.
Example:
“00031D12:34”isdisplayed.
This example shows that an alarm has occurred when the product has been operating for 31
days, 12 hours, and 34 minutes.
