<Appendix 4. Link Master Functions>
270
IM 01E21A02-03EN
A4.5 LM Parameters
A4.5.1 LM Parameter List
The tables below show the list of LM parameters.
Index(SM) Parameter Name
Sub-parameter Name
(Sub Index)
Default Value
Write
mode
Description/
Remarks
283 PLME_BASIC_
CHARACTERISTICS
0 R
1 ChannelStatisticsSupported 0x00
2 MediumAndDataRatesSupported 0x4900000000000000
3 IecVersion 1(0x1)
4 NumOfChannels 1(0x1)
5 PowerMode 0(0x0)
284 CHANNEL_STATES 0 R
1 channel-1 0(0x0)
2 channel-2 128(0x80)
3 channel-3 128(0x80)
4 channel-4 128(0x80)
5 channel-5 128(0x80)
6 channel-6 128(0x80)
7 channel-7 128(0x80)
8 channel-8 128(0x80)
285 PLME_BASIC_INFO 0 R
1 InterfaceMode 0(0x0)
2 LoopBackMode 0(0x0)
3 XmitEnabled 1(0x1)
4 RcvEnabled 1(0x1)
5 PreferredReceiveChannel 1(0x1)
6 MediaTypeSelected 73(0x49)
7 ReceiveSelect 1(0x1)
286 DLME_LINK_MASTER_CAPABILITIES_VARIABLE 0x04 RW
287 DLME_LINK_
MASTER_
INFO_RECORD
0 RW
1 MaxSchedulingOverhead 0
2 DefMinTokenDelegTime 100
3 DefTokenHoldTime 300
4 TargetTokenRotTime 4096
5 LinkMaintTokHoldTime 400
6 TimeDistributionPeriod 5000
7 MaximumInactivityToClaimLasDelay 2
8
LasDatabaseStatusSpduDistributionPeriod
6000
288 PRIMARY_LINK_MASTER_FLAG_VARIABLE 0 RW LAS:True=0xFF;
Non-LAS:False=
0x00
289 LIVE_LIST_STATUS_ARRAY_VARIABLE 0 R
290 MAX_TOKEN_
HOLD_
TIME_ARRAY
0 RW
1 Element1 0x0000(x16),
0x012C(x16)
2 Element2 0x012C(x5),
0x0000(x27)
3 Element3 0x0000(x32)
4 Element4 0x0000(x32)
5 Element5 0x0000(x32)
6 Element6 0x0000(x32)
7 Element7 0x0000(x31),
0x012C(x1)
8 Element8 0x012C(x32)
