7. Parameter Menu Tree
NOTE
The available menus and parameters vary depending on the connection terminal type and the
optional codes selected at the time of ordering.
7.1 Display Menu Tree
The following table provides an overview of the display menu structure.
See the installation manual for general information regarding the operation via display unit.
NOTE
When writing parameters from a display, it is necessary to set all blocks to the O/S mode.
Operation level
Exit R Read only
Operator R/W1 Read and write possible
Maintenance R/W2 Read always possible,
Writing limited to the following operation levels
(Operationlevel:Maintenance,Specialist)
Specialist
R/W3 Read always possible,
Writing limited to the following operation levels
(Operationlevel:Specialist)
Device setup
Block mode Easy setup wizard -> Page 229
All block target
mode
Current alarm -> Page 221
Volume
Language R/W1 Pulse/Status out
Display set
Process variables -> Page 224 Autozero exe
Flowrate(%)
Flow rate Detailed setup -> Page 230
Velocity
All block target
mode
Volume
Mass Pro var
Calorie Sensor
Totalizer Totalizer
Pulse/Status out
Diag/Service -> Page 225 Temperature
All block target
mode
AUX calculation
Display set
Sts/Self test Access cfg
Time stamp Device info
Diagnosis Fieldbus info
Verication Protection
Autozero
Test microSD -> Page 235
Param bkup/restore Contents
Data log Unmount
Disp indicator Format
Property
